GREE Multi Variable Air Conditioners Indoor Unit
255
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND07TD/A-T(U)
CM502N0151
GMV-ND09TD/A-T(U)
CM502N0161
Part code
Quantity
Part code
Quantity
10
Tube Exit Plate Assy
01344100020
1
01344100020
1
11
Electric Box Assy
01394100396
1
01394100396
1
12
Main Board
30226000029
1
30226000029
1
13
Terminal Board
4201026603
1
4201026603
1
14
Terminal Board
4201800002601
1
4201800002601
1
15
Brushless DC Motor
1501214301
1
1501214301
1
16
Strainer
0741410002501
1
0741410002501
1
17
Electronic Expansion Valve
07334492
1
07334492
1
18
Filter
07415210
1
07415210
1
19
Evaporator Assy
0102410009501
1
01024100095
1
20
Water Tray Sub-Assy
01284100011
1
01284100011
1
21
Cross Flow Fan
10454100001
1
10454100001
1
22
Helicoid Tongue sub-assy
02224100007
1
02224100007
1
23
O-Gasket of Cross Fan
Bearing
76512203
1
76512203
1
24
Chassis Assy
01194100007
1
01194100007
1
25
Left Side Plate Sub-Assy
01314100022
1
01314100022
1
Above data is subject to change without notice, please reference the SP in global service website.
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND12TD/A-T(U)
CM502N0181
Part code
Quantity
1
Remote Controller
30510589
1
2
Drain Hose Sub-Assy
05232050
1
3
Temperature Sensor
39008000079G
1
4
Water Level Switch
4501270301
1
5
Water Pump Assy
15404100005
1
6
Pump Drainpipe
26905288
1
7
Water Pump
4313822001
1
8
Hook
02112466
4
9
Right Side Plate Sub-Assy
01314100023
1
10
Tube Exit Plate Assy
01344100020
1
11
Electric Box Assy
01394100396
1
12
Main Board
30226000029
1
13
Terminal Board
4201026603
1
14
Terminal Board
4201800002601
1
15
Brushless DC Motor
1501214301
1
16
Strainer
0741410002501
1
17
Electronic Expansion Valve
07334494
1
18
Filter
07415210
1
19
Evaporator Assy
01024100014
1
20
Water Tray Sub-Assy
01284100011
1
21
Cross Flow Fan
10454100001
1
