Gree GMV-ND160ZD/A-T - Wiring Requirement

Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit
7
Material Type
Total Length L (m)
of Communication
Cable between
Indoor Unit and
Indoor (Outdoor)
Unit
Wire Size
(mm
2
)
Material
Standard
Remarks
Light/Ordinary
polyvinyl
chloride
sheathed cord.
(60227 IEC 52
/60227 IEC 53)
L≤1000m
≥2×0.75 IEC 60227-5
1. If the wire diameter is enlarged to
2×1 mm
2
, the total
communication line length can
reach 1500m.
2. The cord shall be Circular cord
(the cores shall be twisted
together).
3. If unit is installed in places with
intense magnetic field or strong
interference, it is necessary to
use shielded wire.
3.4 Wiring Requirement
Notes:
①
The circuit breaker and power cord specification in above sheet are based on max
power (max current) of the unit.
②
The power cord specification in above sheet is based on ambient temperature of 40°C.
③
The circuit breaker specification in above sheet is based on ambient temperature of
40°C. If the working condition is different, please adjust it according to the specification
sheet of circuit breaker.
Dimension of power cord and capacity of air switch:
Models Power Specification
Air Switch
Capacity
(A)
Minimum Sectional
Area of Grounding
Wire(mm
2
)
Minimum
Sectional Area of
Power Cord (mm
2
)
GMV-ND28ZD/A-T
220-240V-1ph-
50Hz
208-230V-1ph-
60Hz
6 1 1
GMV-ND36ZD/A-T 6 1 1
GMV-ND50ZD/A-T 6 1 1
GMV-ND56ZD/A-T 6 1 1
GMV-ND63ZD/A-T 6 1 1
GMV-ND71ZD/A-T 6 1 1
GMV-ND90ZD/A-T 6 1 1
GMV-ND112ZD/A-T 6 1 1
GMV-ND125ZD/A-T 6 1 1
GMV-ND140ZD/A-T 6 1 1
GMV-ND160ZD/A-T 6 1 1
