Gree GMV-ND22PLS/A-T

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
139
Motor and fan
Step
Diagram
Operation Procedure
6. Remove the
evaporator.
●Remove the evaporator.
7. Unscrew the
motor pressing
board.
●Use a screwdriver to unscrew
the motor pressing board.
8. Remove the
pressing board
and replace the
motor.
●Remove the pressing board and
replace the motor.
9. Screw the
motor pressing
board.
●Use a screwdriver to screw the
motor pressing board.
10. Install the
evaporator.
●Install the evaporator.
