Gree GMV-ND22PLS/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
156
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND90PHS/A-T
CM800N3550
GMV-ND100PHS/A-T
CM800N3650
GMV-ND112PHS/A-T
CM800N3660
GMV-ND125PHS/A-T
CM800N3670
GMV-ND140PHS/A-T
CM800N3680
Part code
Quantity
15
Right Side Plate Sub-Assy
'01315200100
1
16
Electric Box Assy
'01394100255
1
17
Main Board
'30226000027
1
18
Terminal Board
'42011154
1
19
Terminal Board
'4201800002601
1
20
Inductance
'43128000014
1
21
Electric Box Cover
'01424100078
1
22
Blower Mounting Plate Sub-
Assy
'01325200044
1
23
Volute casing(Upper)
'26904100051
2
24
Centrifugal Fan
'10424100001
2
25
Brushless DC Motor
'15709400006
1
26
Volute casing(Lower)
'26904100052
2
27
Top Cover Board Assy
'01264100039
1
28
Hook
'02112466
4
29
Left Side Plate Assy
'01315306
1
30
Sensor Sub-assy
'39004169G
1
31
Dsplay Board
'30296000040
1
Above data is subject to change without notice,pls reference the SP in global service website.
