Gree GMV-ND22PLS/A-T - Page 174

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
170
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-
ND90PLS/A-T
CM800N3450
GMV-
ND125PLS/A-T
CM800N3480
GMV-
ND100PLS/A-T
CM800N3460
GMV-
ND140PLS/A-T
CM800N3470
GMV-
ND112PLS/A-T
CM800N3530
/
/
Part code
Quantity
Part code
Quantity
16
Filter Board
'30226000051
1
'30226000051
1
17
Main Board
'30226000030
1
'30226000030
1
18
Terminal Board
'42011106
1
'42011106
1
19
Terminal Board
'4201800002601
1
'4201800002601
1
20
Right Side Plate Assy
'01314100055
1
'01314100055
1
21
Electric Box Cover
'01425262
1
'01425262
1
22
Seal Of Connection Pipe sub-
assy
'01495238
1
'01495238
1
23
Left Baffler Sub-Assy
'12505217
1
'12505217
1
24
Water Pump
'4313822001
1
'4313822001
1
25
Water Level Switch
'45018012
1
'45018012
1
26
Electronic Expansion Valve
'07334468
1
'07334503
1
27
Strainer
'0741410000601
1
'0741410000601
1
28
Filter Sub-Assy
'07210028
1
'07210028
1
29
Border Plate of Air outlet Sub-
Assy
'02225270
1
'02225270
1
30
Filter
'07415210
1
'07415210
1
31
Evaporator Assy
'01024100106
1
'01024100026
1
32
Water Tray Assy
'01285275
1
'01285275
1
33
Top Cover Board Assy
'0126534901
1
'0126534901
1
34
Choke Plug of Drain Pipe
'76815214
2
'76815214
2
35
Right Baffler Sub-Assy
'12505216
1
'12505216
1
36
Left Side Plate Assy
'01315299
1
'01315299
1
37
Display Board
'30296000040
1
'30296107
1
38
Sensor Sub-assy
'39004169G
1
'39004169G
1
39
Drain Hose Sub-Assy
'05232050
1
'05232050
1
40
Hook
'02112466
4
'02112466
4
