Multi Variable Air Conditioners Ducted Type Indoor Unit
3
If abnormal condition occurs
(e.g. unpleasant smell), please
turn off the unit at once and
disconnect power supply. Then
contact GREE service center. If
the air conditioner continues to
operate despite of abnormal
condition, the unit may be
damaged and it may cause
electric shock or fire hazard).
Do not repair the air conditioner
by yourself. Improper repair will
cause electric shock or fire
hazard. Please contact GREE
service center and have it
repaired by professional
technicians.
Any personal injury or property loss caused by improper installation, improper debug,
unnecessary repair or not following the instructions of this manual should not be the responsibility of
Gree Electric Appliances, Inc. of Zhuhai.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental
safe recycling.
2 Product Introduction
2.1 Names of Key Components
Fig.2.1
2.2 Rated Working Condition
—
Indoor Side Condition Outdoor Side Condition
Dry Bulb Temp(
℃
) Wet Bulb Temp(
℃
) Dry Bulb Temp(
℃
) Wet Bulb Temp(
℃
)
Rated Cooling 27 19 35 24
3 Preparations for Installation
NOTE!
Product graphics are only for reference. Please refer to actual products. Unspecified
measure unit is mm.
