204
DC Inverter Multi
VRF Service Manual
6 969 0.947 62 4017 4.197
7 999 0.979 63 4103 4.288
8 1030 1.012 64 4190 4.381
9 1061 1.046 65 4278 4.475
10 1093 1.080 66 4367 4.570
11 1125 1.114 67 4457 4.666
12 1159 1.150 68 4548 4.763
13 1193 1.186 69 4639 4.860
14 1228 1.224 70 4731 4.958
15 1263 1.261 71 4893 5.130
5�2 Features of the Low Pressure Sensors (R410a)
Temp.( ) Absolute Pressure(kPa) Volt. (V) Temp. ( ) Absolute Pressure(kPa) Volt. (V)
-70 36 0.369 -14 502 1.301
-69 38 0.373 -13 520 1.337
-68 40 0.377 -12 538 1.373
-67 43 0.383 -11 558 1.413
-66 46 0.389 -10 577 1.451
-65 48 0.393 -9 597 1.491
-64 51 0.399 -8 618 1.533
-63 54 0.405 -7 639 1.575
-62 57 0.411 -6 661 1.619
-61 61 0.419 -5 684 1.665
-60 64 0.425 -4 707 1.711
-59 68 0.433 -3 730 1.757
-58 72 0.441 -2 754 1.805
-57 76 0.449 -1 799 1.895
-56 80 0.457 0 804 1.905
-55 84 0.465 1 830 1.957
-54 89 0.475 2 857 2.011
-53 94 0.485 3 884 2.065
-52 99 0.495 4 912 2.121
-51 104 0.505 5 940 2.177
-50 109 0.515 6 969 2.235
-49 115 0.527 7 999 2.295
-48 121 0.539 8 1030 2.357
-47 127 0.551 9 1061 2.419
-46 133 0.563 10 1096 2.489
-45 140 0.577 11 1125 2.547
-44 146 0.589 12 1159 2.615
-43 154 0.605 13 1193 2.683
-42 161 0.619 14 1228 2.753
-41 168 0.633 15 1263 2.823
-40 176 0.649 16 1300 2.897
-39 184 0.665 17 1337 2.971
-38 193 0.683 18 1375 3.047
-37 202 0.701 19 1413 3.123
-36 211 0.719 20 1453 3.203
