Outdoor Units_Heat Recovery To n 24 26
Model - GMV-Q288WM/B-F(U) GMV-Q312WM/B-F(U)
Module combination -
GMV-Q96WM/B-F(U)+
GMV-Q96WM/B-F(U)+
GMV-Q96WM/B-F(U)
GMV-Q96WM/B-F(U)+
GMV-Q96WM/B-F(U)+
GMV-Q120WM/B-F(U)
Performance
Nominal Cooling
Capacity
Btu/h 288000 312000
kW 84.4 91.4
Rated Cooling
Capacity
Btu/h 270000 291000
Nominal Heating
Capacity
Btu/h 324000 351000
kW 95.0 102.9
Rated Heating
Capacity
Btu/h 300000 326000
Cooling Power Input kW 7.3+7.3+7.3 7.3+7.3+9.58
Heating Power Input kW 7.85+7.85+7.85 7.85+7.85+10.42
Sound Pressure Level dB(A) - -
Power Supply - 208/230V 3~ 60Hz
Compressor
Type - Inverter scroll type Inverter scroll type
Number N 1+1+1 1+1+2
Motor Output
①
kW - -
Starting Method - Inverter Inverter
Operating Range - - -
Refrigeration Oil Brand - FVC68D or FV-68H FVC68D or FV-68H
Fan
Type× Quantity - Propeller×(2+2+2) Propeller×(2+2+2)
Motor output W 750×2+750×2+750×2 750×2+750×2+750×2
Starting method - Inverter Inverter
Air ow rate
m
3
/h 14000+14000+14000 14000+14000+14000
cfm 8240+8240+8240 8240+8240+8240
Max. external static
pressure
Pa 82 82
in.W.G 0.328 0.328
Ambient
temperature range
Cooling
°C -5~52 -5~52
℉
23~125.6 23~125.6
Heating
°C -20~24 -20~24
℉
-4~75.2 -4~75.2
Refrigerant
Refrigerant Type - R410A R410A
Refrigerant Charge
Volume
kg 11.2+11.2+11.2 11.2+11.2+11.7
lbs. 24.69+24.69+24.69 24.69+24.69+25.79
Control - EXV EXV
Pipe Connection
Low pressure Gas
Pipe Size
mm 34.9 34.9
in. 1 3/8 1 3/8
high pressure gas pipe
mm 28.6 28.6
in. 1 1/8 1 1/8
Liquid Pipe Size
mm 19.05 19.05
in. 3/4 3/4
