GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 28 30
Model - GMV-Q336WM/B-F(U) GMV-Q360WM/B-F(U)
Module combination -
GMV-Q96WM/B-F(U)+
GMV-Q120WM/B-F(U)+
GMV-Q120WM/B-F(U)
GMV-Q120WM/B-F(U)+
GMV-Q120WM/B-F(U)+
GMV-Q120WM/B-F(U)
Pipe
Connection
Low pressure Gas
Pipe Size
mm 34.9 41.3
in. 1 3/8 1 5/8
high pressure gas
pipe
mm 28.6 34.9
in. 1 1/8 1 3/8
Liquid Pipe Size
mm 19.05 19.05
in. 3/4 3/4
Dimensions
(width× depth×
height)
External
Dimension
mm
1340×765×1605
+1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
+1340×765×1605
in.
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
Packaging
Dimension
mm
1420×840×1775
+1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
+1420×840×1775
in.
55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
Weight
Net Weight
kg 310+360+360 360+360+360
lbs. 683+794+794 794+794+794
Gross Weight
kg 325+375+375 375+375+375
lbs. 716+827+827 827+827+827
Maximum qty of connected indoor
units
unit 56 59
Protection
Devices
High Pressure
Protection
High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/Low voltage protection,
Remark
① .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
;
Evaporating temp.45
℉
; Return gas temp.65
℉
; Liquid temp.115
℉
) at 60Hz.
② .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall
be charged.
