19
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 6 8 10
Model - GMV-Q72WM/B-U(U) GMV-Q96WM/B-U(U) GMV-Q120WM/B-U(U)
Module combination - GMV-Q72WM/B-U(U) GMV-Q96WM/B-U(U) GMV-Q120WM/B-U(U)
Dimensions
(width× depth×
height)
External Dimension
mm 1340×765×1605 1340×765×1605 1340×765×1605
in. 52-3/4×30-1/8×63-1/5 52-3/4×30-1/8×63-1/5 52-3/4×30-1/8×63-1/5
Packaging Dimension
mm 1420×840×1775 1420×840×1775 1420×840×1775
in. 55-7/8×33-1/8×69-7/8 55-7/8×33-1/8×69-7/8 55-7/8×33-1/8×69-7/8
Weight
Net Weight
kg 305 315 370
lbs. 672 694 816
Gross Weight
kg 320 330 385
lbs. 705 728 849
Maximum qty of connected indoor units unit 13 16 19
Protection
Devices
High Pressure Protection High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/ Low voltage protection,
Remark
① .
Rating conditions
：
Cooling
：
indoor 26.7
℃
(80
℉
) D.B./19.4
℃
(67
℉
)W.B;outdoor:35
℃
(95
℉
) D.B.
Heating
：
indoor 21.1
℃
(70
℉
) D.B.;outdoor:8.3
℃
(47
℉
) D.B./6.1
℃
(43
℉
) W.B
② .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
, Evaporating
temp.45
℉
, Return gas temp.65
℉
. Liquid temp.115
℉
) at 60Hz.
③ .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall be
charged.
