GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 12 14
16
Model - GMV-Q144WM/B-U(U) GMV-Q168WM/B-U(U) GMV-Q192WM/B-U(U)
Module combination -
GMV-Q72WM/B-U(U)+
GMV-Q72WM/B-U(U)
GMV-Q72WM/B-U(U)+
GMV-Q96WM/B-U(U)
GMV-Q96WM/B-U(U)+
GMV-Q96WM/B-U(U)
Pipe
Connection
Low pressure Gas
Pipe Size
mm 28.6 28.6 28.6
in. 1 1/8 1 1/8 1 1/8
High pressure gas
pipe
mm
Φ
22.2
Φ
22.2 28.6
in. 7/8 7/8 1 1/8
Liquid Pipe Size
mm 12.7 15.9 15.9
in. 1/2 5/8 5/8
Dimensions
(width×
depth× height)
External Dimension
mm
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
in.
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-
1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-
1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-
1/5
Packaging
Dimension
mm
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
in.
55-7/8×33-1/8×69-
7/8+55-7/8×33-
1/8×69-7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-
1/8×69-7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-
1/8×69-7/8
Weight
Net Weight
kg 305+305 305+315 315+315
lbs. 672+672 672+694 694+694
Gross Weight
kg 320+320 320+330 320+330
lbs. 705+705 705+728 728+728
Maximum qty of connected indoor units unit 23 29 33
Protection
Devices
High Pressure
Protection
High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/Low voltage protection,
Remark
① .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
;
Evaporating temp.45
℉
; Return gas temp.65
℉
; Liquid temp.115
℉
) at 60Hz.
② .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall
be charged.
