GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 18 20 22
Model - GMV-Q216WM/B-U(U) GMV-Q240WM/B-U(U) GMV-Q264WM/B-U(U)
Module combination -
GMV-Q96WM/B-U(U)+
GMV-Q120WM/B-U(U)
GMV-Q120WM/B-U(U)+
GMV-Q120WM/B-U(U)
GMV-Q72WM/B-U(U)+
GMV-Q96WM/B-U(U)+
GMV-Q96WM/B-U(U)
Pipe
Connection
Low pressure Gas
Pipe Size
mm 28.6 34.9 34.9
in. 1 1/8 1 3/8 1 3/8
high pressure gas
pipe
mm 28.6 28.6 28.6
in. 1 1/8 1 1/8 1 1/8
Liquid Pipe Size
mm 15.9 15.9 19.05
in. 5/8 5/8 3/4
Dimensions
(width×
depth× height)
External Dimension
mm
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
+1340×765×1605
in.
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
Packaging
Dimension
mm
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
+1420×840×1775
in.
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
Weight
Net Weight
kg 315+370 370+370 305+315+315
lbs. 694+816 816+816 672+694+694
Gross Weight
kg 330+385 385+385 320+330+330
lbs. 728+849 849+849 705+728+728
Maximum qty of connected indoor
units
unit 36 39 46
Protection
Devices
High Pressure
Protection
High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/Low voltage protection,
Remark
① .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
;
Evaporating temp.45
℉
; Return gas temp.65
℉
; Liquid temp.115
℉
) at 60Hz.
② .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall
be charged.
