Gree GMV5 Series

38
6 UNIT CAPACITY CORRECTION
6.1 Correction of Capacity Along with Ambient Temperature and Conguration Ratio
GMV-Q***WM/B-F(U) Cooling Capacity Correction Table for GMV5 HR VRF Unit
GMV-Q72WM/B-F(U)
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor
air temp
（℉
DB
）
Indoor air temp
57.2
℉
WB 60.8
℉
WB 64.4
℉
WB 66.2
℉
WB 68
℉
WB 71.6
℉
WB 75.2
℉
WB
68
℉
DB 73.4
℉
DB 78.8
℉
DB 80.6
℉
DB 82.4
℉
DB 86
℉
DB 89.6
℉
DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
130%
50 63.3 2.51 75.3 3.07 87.4 3.65 90.8 3.73 91.8 3.66 94.1 3.51 96.4 3.34
53.6 63.3 2.56 75.3 3.13 87.4 3.73 89.5 3.71 90.8 3.64 92.8 3.48 95.1 3.43
57.2 63.3 2.61 75.3 3.19 87.2 3.77 88.5 3.70 89.5 3.62 91.8 3.59 94.1 3.62
60.8 63.3 2.65 75.3 3.26 86.1 3.76 87.2 3.73 88.2 3.74 90.5 3.78 92.8 3.81
64.4 63.3 2.70 75.3 3.32 84.9 3.90 85.9 3.92 87.2 3.94 89.5 3.98 91.8 4.01
68 63.3 2.76 75.3 3.54 83.6 4.09 84.9 4.11 85.9 4.13 88.2 4.17 90.5 4.21
69.8 63.3 2.84 75.3 3.66 83.1 4.18 84.3 4.20 85.4 4.23 87.7 4.27 90.0 4.31
73.4 63.3 3.04 75.3 3.92 82.0 4.37 83.1 4.40 84.1 4.42 86.4 4.46 88.7 4.51
77 63.3 3.25 75.3 4.20 80.7 4.56 82.0 4.59 83.1 4.62 85.4 4.66 87.7 4.70
80.6 63.3 3.47 75.3 4.50 79.7 4.02 80.7 4.78 81.8 4.81 84.1 4.86 86.4 4.91
84.2 63.3 3.70 75.3 4.81 78.4 4.95 79.5 4.98 80.7 5.01 83.1 5.06 85.4 5.11
87.8 63.3 3.95 75.1 5.09 77.1 5.15 78.4 0.76 79.5 5.20 81.8 5.26 84.1 5.31
91.4 63.3 4.21 73.8 5.28 76.1 5.33 77.1 5.37 78.4 5.39 80.7 5.45 82.8 5.52
95 63.3 4.49 72.5 5.47 74.8 5.53 76.1 5.56 77.1 5.59 79.5 5.66 81.8 5.72
98.6 63.3 4.78 71.5 5.67 73.8 5.73 74.8 5.76 76.1 5.80 78.2 5.87 80.5 5.93
102.2 63.3 5.09 70.2 5.86 72.5 5.92 73.8 5.96 74.8 6.00 77.1 6.06 79.5 6.14
Combination
Outdoor
air temp
（℉
DB
）
Indoor air temp
57.2
℉
WB 60.8
℉
WB 64.4
℉
WB 66.2
℉
WB 68
℉
WB 71.6
℉
WB 75.2
℉
WB
68
℉
DB 73.4
℉
DB 78.8
℉
DB 80.6
℉
DB 82.4
℉
DB 86
℉
DB 89.6
℉
DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
120%
50 58.4 2.29 69.4 2.80 80.7 3.33 86.4 3.60 90.5 3.76 92.6 3.61 94.6 3.47
53.6 58.4 2.34 69.4 2.85 80.7 3.40 86.4 3.67 89.2 3.73 91.3 3.59 93.3 3.45
57.2 58.4 2.38 69.4 2.91 80.7 3.46 86.4 3.74 87.9 3.71 90.3 3.57 92.3 3.59
60.8 58.4 2.43 69.4 2.97 80.7 3.53 85.9 3.77 86.9 3.72 89.0 3.76 91.0 3.79
64.4 58.4 2.47 69.4 3.03 80.7 3.65 84.6 3.90 85.6 3.91 87.7 3.95 90.0 3.98
68 58.4 2.52 69.4 3.15 80.7 3.92 83.6 4.09 84.6 4.10 86.7 4.14 88.7 4.17
69.8 58.4 2.54 69.4 3.26 80.7 4.06 82.8 4.18 83.8 4.20 86.1 4.23 88.2 4.28
73.4 58.4 2.72 69.4 3.49 80.7 4.35 81.8 4.37 82.8 4.39 84.9 4.43 86.9 4.47
77 58.4 2.90 69.4 3.73 79.5 4.54 80.5 4.56 81.5 4.58 83.8 4.62 85.9 4.67
80.6 58.4 3.10 69.4 3.99 78.4 4.73 79.5 4.76 80.5 4.78 82.5 4.82 84.6 4.87
84.2 58.4 3.31 69.4 4.26 77.1 4.92 78.2 4.95 79.2 4.97 81.3 5.02 83.6 5.06
87.8 58.4 3.53 69.4 4.55 76.1 5.12 77.1 5.14 78.2 5.17 80.2 5.22 82.3 5.27
91.4 58.4 3.76 69.4 4.86 74.8 5.31 75.9 5.34 76.9 5.36 78.9 5.42 81.0 5.47
95 58.4 4.00 69.4 5.17 73.5 5.50 74.6 5.53 75.9 5.56 77.9 5.62 80.0 5.67
98.6 58.4 4.26 69.4 5.51 72.5 5.70 73.5 5.73 74.6 5.76 76.6 5.81 78.7 5.88
102.2 58.4 4.53 69.2 5.82 71.2 5.89 72.3 5.92 73.3 5.95 75.6 6.02 77.7 6.08
