GREE U-Match 5 SERIES UNIT SERVICE MANUAL
123
Model: GUD100W/NhA-T, GUD125W/NhA-T, GUD140W/NhA-T, GUD100W/NhA-X, GUD125W/NhA-X,
GUD140W/NhA-X
Removal of fan and motor
Note: Before removing the fan, make sure power is cut off.
Step Picture Work instruction
1. Remove the grill.
 Use a screwdriver to
unscrew the two screws
on the upper left and lower
right corners.
2. Remove the fan.
 Use a wrench to remove
the specialized nut and
gasket of the fan.
Note: Please keep the nut
and gasket safe after
removing them from the
fan.
3. Remove motor.
 Use a screwdriver to
unscrew the bolt of motor.
Note: Motor wire should
be first removed from the
electric box.
4. Install the motor.
 Replace with a new motor.
Then tighten up the screw
bolt.
