Gree GVA24AL-K3NNC7A/I User Manual

Service Manual
2
Technical Information
2. Specications
2.1 Specication Sheet
Parameter Unit Value
Model GVA24AL-K3NNC7A
Product Code CG156000200
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity W 7055
Heating Capacity W 7800+2100
Cooling Power Input W 2430
Heating Power Input W 2350
Cooling Power Current A 10.49
Heating Power Current A 10.15
Rated Input W 4800
Rated Current
A 12.09
Air Flow Volume(SH/H/M/L/SL) m
3
/h
1100/1000/900/800/-
Dehumidifying Volume L/h
2.50
EER
W/W
2.90
COP W/W 3.32
SEER W/W /
HSPF W/W /
Application Area m
2
32-50
Indoor Unit
Model of indoor unit GVA24AL-K3NNC7A/I
Product Code CG156N00200
Fan Type Centrifugal
Diameter Length(DXL) mm Φ350X130.5
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 450/415/380/345/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 450/415/380/345/-
Output of Fan Motor W 60
Fan Motor RLA A 0.72
Fan Motor Capacitor μF 4
Heater Power Input W 2100
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2 - 1.3
Coil Length (LXDXW) mm 724X25.4X392
Swing Motor Model MP35AA/MP24TA
Output of Swing Motor W 2.5/1.5
Fuse A 5
Sound Pressure Level (SH/H/M/L/SL) dB (A) 46/44/41/38/-
Sound Power Level (SH/H/M/L/SL) dB (A) 56/54/51/48/-
Dimension (WXHXD) mm 507X1770X320
Dimension of Carton Box (LXWXH) mm 1985X620X425
Dimension of Package(LXWXH) mm 1988X623X440
Net Weight kg 40
Gross Weight kg 52
