Service Manual
58
Installation and Maintenance
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGVA48AL-M3NNC7A/I GVA55AL-M3NNC7A/I
Product Code CG156N00300 CG156N00100
1 Right Side Plate Sub-Assy 0130451801 0130451801 1
2 Rear Plate Assy 01304290 01304290 1
3 Right Air Guard 01364507 01364507 1
4 Top Cover Sub-Assy 000051000034 000051000034 1
5 Left Air Guard 01364506 01364506 1
6 Left Side Plate Sub-Assy 0130451901 0130451901 1
7 Evaporator Assy 011001000482 011001000601 1
8 Air Guard Assy 01364509 01364509 1
9 Rear Grill 01474014 01474014 1
10 Chassis 200148000005 200148000005 1
11 Wire Clamp 01384201 01384201 1
12 Fan Motor 1501443307 1501443307 1
13 Water Tray Sub-Assy 12314811 12314811 1
14 Breakwater Sub-Assy 01364154P 01364154P 1
15 Protection Cover 20124062 20124062 1
16 Remote Control Panel Sub-assy 20903400001 20903400001 3
17 Centrifugal Fan 10314401 10314401 1
18 Propeller Housing Sub-assy 12104058 12104058 1
19 Diversion Circle 10374435 10374435 1
20 Gasket 70414201 70414201 1
21 Electric Box Cover Sub-Assy 01404388 01404388 1
22 Electric Box Assy 100002002913 100002002913 1
23 Main Board 300002000687 300002000687 1
24 Capacitor CBB61S 3301074707 3301074707 1
25 Terminal Board 42010052 42010052 1
26 Motor Cover 22244170 22244170 1
27 SteppingMotor 1521210104 1521210104 1
28 Air Guide Bushing 1054420302 1054420302 6
29 Guide Blade Lever 200235000004 200235000004 1
30 SteppingMotor 15212115 15212115 1
31 Crank 1 10564204 10564204 1
32 Air Louver 1 200007000028 200007000028 1
33 Air Louver 2 200007000029 200007000029 5
34 Crankshaft of Guide Louver 1056420502 1056420502 6
35 Guide Louver 200004000023 200004000023 6
36 Air Outlet Panel Assy 000039000005 000039000005 1
37 Display Sub-Assy 000057000030 000057000030 1
38 Display Board 300001000198 300001000198 1
39 Remote Controller 305001000125 305001000125 1
40 Screw Cover 200005000006 200005000006 2
41 Air Intake Panel Assy 209006000002 209006000002 1
42 Filter (lower) 11124012 11124012 1
43 Filter Sub-assy(Upper) 111001000032 111001000032 1
44 Connecting Cable 4003213471 4003213471 1
45 Connecting Cable 400205399 400205399 1
46 Connecting Cable 4002053910 4002053910 1
To Next Page
