Service Manual
60
Installation and Maintenance
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGVA24AL-K3NNC7A/O
Product Code CG156W00200
1 Front Grill 22415010 1
2 Front Panel 01535013P 1
3 Axial Flow Fan 10335008 2
4 Drainage Joint 06123401 1
5 Drainage hole Cap 06813401 1
6 Chassis Sub-assy 017000000276P 1
7 Compressor and Fittings 009001000217 1
8 Right Side Plate Assy 0130329201 1
9 Valve Support Sub-Assy 01705046P /
10 Cut off Valve Sub-Assy(1/4) 030057000029 1
11 Cut off Valve Sub-Assy 030057000050 1
12 Valve Cover 22245002 1
13 Handle 26233053 /
14 Condenser Assy 011002000688 1
15 4-Way Valve Assy 030152000406 2
16 Magnet Coil 4300040047 1
17 Clapboard 01245200018 /
18 Motor Support Sub-Assy 01705036 1
19 Rear Grill 01473043 1
20 Coping 012049000007P 1
21 Electric Box Cover 01429400023 1
22 Fan Motor 1501506310 1
23 Left Side Plate 01305093P 1
24 Handle 2623525404 1
25 Capacitor CBB61S 3301074706 1
26 Transformer 43118000004 1
27 Electric Box 1 01429400024 1
28 Jumper 4202300103 /
29 Main Board 300027000489 1
30 AC Contactor 44010245 1
31 Capacitor CBB65 3300008113 1
32 Electric Box Assy 100002003738 1
33 Terminal Board 420001000002 2
34 Insulation Gasket 70410503 1
35 Wire Clamp 71010102 1
36 Supporting Board(Condenser) 01795010 1
