Service Manual
77
Installation and Maintenance
Procedure
Step
16.Remove left and right side plate sub-assys
Right side plate sub-assy
Left side plate sub-assy
Remove screws at both sides, pull them to
both sides respectively and then left and right
plate sub-assys can be removed.
To Next Page
