Service Manual
84
Installation and Maintenance
Procedure
Steps
3.Remove grille
4.Remove front side plate
5.Remove right side plate
Remove screws used for xing the
grille and the rear side plate, the grille
and the chassis, and then remove the
grille.
Remove screws used for xing the front side
plate, lift the front side plate upwards and
then remove it.
Remove screws used for xing the right side
plate, and then remove the right side plate.
Grille
Screw Screw
Front side plate
Right side plate
To Next Page
