Service Manual
86
Installation and Maintenance
Valve
Compressor
Gas-liquid separator
9.Remove 4-way valve
10.Remove valve
Twist off the nuts used for xing the 4-way
valve wire, and then take out the coil. Use wet
guaze to wrap the 4-way valve, unsolder the
spot weld connected to the 4-way valve and
then remove the 4-way valve. The welding
process must be as quick as possible, and
then gauze should be kept wet all the time.
Please note that don’t let the ame burn the
leading wired of compressor.
Remove screws used for xing the valve,
unsolder the pipeline connected with the valve
and then remove the valve.
11.Remove compressor sub-assy
Unsolder the pipeline connected with the
compressor, remove 3 foot nuts on the
compressor, and then the compressor and the
gas-liquid separator can be removed.
4-way valve
Procedure
Steps
