Service Manual
6
Technical Information
Parameter Unit Value
Model GVA55AL-M3NNC7A
Product Code CG156000100
Power
Supply
Rated Voltage V~ 380-415
Rated Frequency Hz 50
Phases 3
Power Supply Mode Outdoor
Cooling Capacity W 15200
Heating Capacity W 17000+3500
Cooling Power Input W 5410
Heating Power Input W 5290
Cooling Power Current A 11.72
Heating Power Current A 11.24
Rated Input W 11100
Rated Current A 17.6
Air Flow Volume(SH/H/M/L/SL) m
3
/h 1800/1650/1500/1350/-
Dehumidifying Volume L/h 5.5
EER W/W 2.81
COP W/W 3.21
SEER W/W /
HSPF W/W /
Application Area m
2
80-100
Indoor Unit
Model of indoor unit GVA55AL-M3NNC7A/I
Product Code CG156N00100
Fan Type Centrifugal
Diameter Length(DXL) mm Φ369X180.5
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 550/490/440/390/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 550/490/440/390/-
Output of Fan Motor W 150
Fan Motor RLA A 1.50
Fan Motor Capacitor μF 6
Heater Power Input W 3500
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 3-1.4
Coil Length (LXDXW) mm 876X25.4X472
Swing Motor Model MP24TA /MP35AB
Output of Swing Motor W 1.5/2.5
Fuse A 5
Sound Pressure Level (SH/H/M/L/SL) dB (A) 52/50/47/44/-
Sound Power Level (SH/H/M/L/SL) dB (A) 62/60/57/54/-
Dimension (WXHXD) mm 587X1882X394
Dimension of Carton Box (LXWXH) mm 2150X735X530
Dimension of Package(LXWXH) mm 2153X738X545
Net Weight kg 61
Gross Weight kg 83.5
To Next Page
