84
Installation and Maintenance
Service Manual
Step Procedure
15.Remove motor and cross ow blade
Motor clamp
Remove the screws xing motor clamp
and then remove the motor clamp.
Remove the screws at the connection
place of cross ow blade and motor; lift
the motor and cross ow blade upwards
to remove them.
Remove the bearing holder sub-assy.
a.
b.
c.
Screws
Cross ow
Holder sub-assy
Motor
Screw
