87
Installation and Maintenance
Service Manual
Remove the screws fixing left side plate and
condenser support board, to remove the left side plate.
6. Remove left side plate
left side plate
Remove the screw nut fixing cross fan blade, remove
the gasket and spring cushion, to remove the cross
fan blade.
7. Remove cross fan blade
cross fan blade
Remove the screws fixing right side plate and valve
support, to remove the right side plate.
8. Remove right side plate
right side plate
