Technical Information
Service Manual
Model
GWH12YD-S6DBA1A
GWH12YD-S6DBA2A
Product Code
CB437003001
CB466000204
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 3530
Heating Capacity W 4200
Cooling Power Input W 840
Heating Power Input W 950
Cooling Power Current A 5.10
Heating Power Current A 5.70
Rated Input W 2600
Rated Current A 12
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 800/730/680/630/580/530/430
Dehumidifying Volume
L/h 1.40
EER W/W
4.20
COP W/W
4.42
SEER
W/W 8.50
HSPF W/W /
Application Area m
2
16-24
Indoor Unit
Model of indoor unit
GWH12YD-S6DBA1A/I
GWH12YD-S6DBA2A/I
Indoor Unit Product Code
CB437N03001
CB466N00204
Fan Type Cross-ow
Diameter Length(DXL) mm Φ106X706
Fan Motor Cooling Speed r/min 1200/1100/1030/960/890/820/750/500
Fan Motor Heating Speed r/min 1300/1200/1120/1040/960/880/800/-
Output of Fan Motor W 60
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.4
Coil Length (LXDXW) mm 715X25.4X304.8
Swing Motor Model MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5
Fuse A 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/
SL)
dB (A) 46/43/41/38/36/34/21
Sound Power Level (SH/H/MH/M/ML/L/SL) dB (A) 58/55/53/50/48/46/33
Dimension (WXHXD) mm 996X301X225
Dimension of Carton Box (LXWXH) mm 1057X377X307
Dimension of Package (LXWXH) mm 1060X380X322
Net Weight kg 13.5
Gross Weight kg 16.5
2. Specications
2.1 Specication Sheet

Gree GWH12YD-S6DBA1A Specifications

General

Brand	Gree
Model	GWH12YD-S6DBA1A
Category	Air Conditioner
Language	English
