4
Technical Information
Service Manual
Model
3VIR09HP230V1A
Product Code CB385002900
Power
Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode outdoor
Cooling Capacity Btu/h 9100
Heating Capacity W 3224
Cooling Power Input W 618
Heating Power Input W 860
Cooling Power Current A 3.0
Heating Power Current A 4.2
Rated Input W 1650
Rated Cooling Current A 7.2
Rated Heating Current A 7.2
Air Flow Volume(SS/H/MH/M/ML/L/SL/SM) CFM
353/324/294/265/235/206/194/129
Dehumidifying V
olume Pint/h 1.69
EER (Btu/h)/W 14.70
COP (Btu/h)/W 12.79
SEER 25.3
HSPF 11.2
Application Area yd
2
14.35-21.53
Indoor
Unit
Model of indoor unit
3VIR09HP230V1AH
Indoor Unit Product Code CB385N02900
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ98X630
Cooling Speed r/min
1300/1200/1100/1000/900/800/750/500
Heating Speed r/min
1300/1200/1100/1000/900/850/800/-
Fan Motor Power Output W 15
Fan Motor RLA A 0.22
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm
634 X 22.8 X 304.8
Swing Motor Model MP24AK/MP24BA/MP24HF
Swing Motor Power Output W 1.5/1.5/1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling: 40/37/35/32/29/26/25/22
Heating: 41/38/36/33/29/27/25/
-
Sound Power Level dB (A)
Cooling: 50/47/45/42/39/36/35/32
Heating: 51/48/46/43/39/37/35/
-
Dimension (WXHXD) inch 32 31/64 X 11 34/64 X 7 46/64
Dimension of Carton Box (LXWXH) inch 34 16/64 X 13 47/64 X 10 8/64
Dimension of Package (LXWXH) inch 34 29/64 X 14 24/64 X 10 35/64
Net Weight Ib 20.9
Gross Weight Ib 25.4
2. Specications
