6
Technical Information
Service Manual
Model
3VIR12HP115V1A
Product Code CB385006200
Power
Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 12100
Heating Capacity W 12100
Cooling Power Input W 931
Heating Power Input W 982
Cooling Power Current A 8.26
Heating Power Current A 8.53
Rated Input W 1500
Rated Cooling Current A 12.45
Rated Heating Current A 13.1
Air Flow Volume(SS/H/MH/M/ML/L/SL/SM) CFM 400/365/330/288/265/247/230/212
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 13.00
COP (Btu/h)/W 12.32
SEER 25
HSPF 11.5
Application Area yd
2
19-29
Indoor
Unit
Model of indoor unit
3VIR12HP115V1AH
Indoor Unit Product Code CB385N06200
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ98X630
Cooling Speed r/min 1450/1200/1120/1050/980/920/750/500
Heating Speed r/min 1450/1200/1140/1080/1020/960/900/-
Fan Motor Power Output W 15
Fan Motor RLA A 0.30
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm
634X22.8X304.8
Swing Motor Model MP24BA/MP24AK/MP24HF
Swing Motor Power Output W 1.5/1.5/1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling: 43/38/35/33/31/29/25/20
Heating: 44/38/36/34/32/30/28/-
Sound Power Level dB (A)
Cooling: 53/48/45/43/41/39/35/30
Heating: 54/48/46/44/42/40/38/-
Dimension (WXHXD) inch 32 31/64 X 11 34/64 X 7 46/64
Dimension of Carton Box (LXWXH) inch 34 16/64 X 13 47/64 X 10 8/64
Dimension of Package (LXWXH) inch 34 29/64 X 14 24/64 X 10 35/64
Net Weight Ib 20.9
Gross Weight Ib 25.4
2. Specications
