Greenheck ECV Series User Manual

Energy Core Ventilator 19
®
MODULATING CONTROL FOR FAN SPEED
(0-10 VDC)
Parameter
Setting
V1000 J1000
A1-01 Access Level 2 2
B1-17 VFD Start-Up Setting 1 1
C6-02 Carrier Frequency 1 1
D2-02 Ref Lower Limit 50% 50%
E2-01 Motor Rated FLA
Motor
FLA
Motor
FLA
H2-01 Terminal MA, MC Function 5 5
H3-04 Terminal A1 Bias 50% 50%
L4-01 H2-01 Frequency Detection 15 15
L5-01 Auto Restart Attempt 5 5
A1-01 Access Level 0 0
CO
2
SENSOR CONTROL FOR FAN SPEED
(1/2 SPEED WHEN CO
2
DROPS BELOW 700 PPM)
(FULL SPEED WHEN CO
2
RISES ABOVE 800 PPM)
MULTI-SPEED CONTROL FOR FAN SPEED
(1/3 OR 1/2 SPEED REDUCTION)
Parameter
Setting
V1000 J1000
A1-01 Access Level 2 2
B1-01
Reference Source
(Frequency)
00
B1-17 VFD Start-Up Setting 1 1
C6-02 Carrier Frequency 1 1
D1-01 Frequency Reference 1 60 Hz 60 Hz
D1-02 Frequency Reference 2 40 Hz 40 Hz
D1-03 Frequency Reference 3 30 Hz 30 Hz
D1-04 Frequency Reference 4 60 Hz 60 Hz
D2-02 Ref Lower Limit 50% 50%
E2-01 Motor Rated FLA
Motor
FLA
Motor
FLA
H1-04
Multi-Function Input Sel 4
(Terminal S4)
33
H1-05
Multi-Function Input Sel 5
(Terminal S5)
44
H1-06
Multi-Function Input Sel 6
(Terminal S6)
5NA
H2-01 Terminal MA, MC Function 5 5
H3-10 A2 Not Used F NA
L4-01 H2-01 Frequency Detection 15 15
L5-01 Auto Restart Attempt 5 5
A1-01 Access Level 0 0
CO
2
PROPORTIONAL CONTROL
Parameter
Setting
V1000 J1000
B1-17 VFD Start-Up Setting 1 1
C6-02 Carrier Frequency 1 1
D2-02 Ref Lower Limit 50% 50%
E2-01 Motor Rated FLA FLA FLA
H3-03
Analog Frequency
Reference (Gain)
150% 150%
H3-04
Analog Frequency
Reference (Bias)
25% 25%
L2-01 Ride Thru Power Loss 2 2
L4-05 Frequency Ref Loss 0 NA
L5-01 Auto Restart Attempt 5 5
A1-01 Access Level 0 0
