Sidewall Propeller Fans
Table of Contents
Model Comparison .........................3
Direct Drive Construction & Material Data ..... 4
Belt Drive Construction & Material Data ........ 5
Accessories and Options ..................6-7
Mounting Options .......................8-12
Basics of Fan Selection ....................13
Sidewall Mounting Options...............11-15
Dimensions for Sidewall Propeller .........16-17
Dampers .............................18-19
Direct Drive Dimensional Data .............. 20
Belt Drive Dimensional Data .................21
Vari-Green
®
Options .................... 22-23
Model Number Code ..................... 24
Direct Drive Level 1 ........................25
Direct Drive Level 2 ........................26
Direct Drive Level 3 ........................27
Direct Drive Level 3 Reversible...............28
Belt Drive .............................29-41
Specifications .........................42-43
Direct Drive Specifications ..................40
Sidewall Direct Drive, Sidewall Belt Drive, Sidewall
Belt Driven Cast and Sidewall Cast models
are listed
for electrical (UL/cUL 705) File no. E40001
*UL is optional and must be specified
Greenheck Fan Corporation certifies that the SB, SBC, S1, S2 and
SC3 models shown herein are licensed to bear the AMCA Seal.
The ratings shown are based on tests and procedures performed
in accordance with AMCA Publication 211 and AMCA Publication
311 and comply with the requirements of the AMCA Certified
Ratings Program.
Sidewall propeller fans are ideal
for high volumes of air and low pressure requirements.
For general ventilation to industrial duty,
range of construction and performance capabilities
represents the most comprehensive sidewall
propeller fan line in the industry.
Typical Installations
• Factories
• Warehouses
Sidewall Propeller Benefits
• Exhaust or supply arrangements
• Fabricated steel, aluminum or cast aluminum
propellers
• Drive frames and panels are constructed to
match the level of duty and the motor size
• Three airflow directions; exhaust, supply
and reversible
• Both belt drive and direct drive models
• Three levels of construction from commercial
to industrial
• Multiple blade designs for low sound and
optimum efficiency
