S1-Direct Drive - Level 1
Performance certified is for Models S1 for installation type A: free inlet, free outlet. Power rating (Bhp) does not include transmission losses. Performance ratings do not include
the effects of appurtenances (accessories). The sound ratings shown are loudness values in fan sones at 5 ft (1.5 m) in a hemispherical free field calculated per AMCA Standard 301.
Values are for installation type A: free inlet hemispherical sone levels.
Model Number
Motor
HP
Fan
RPM
Max
BHP
Sones
@ Free
Air
CFM/Static Pressure in Inches WG
0.00 0.05 0.10 0.125 0.15 0.20 0.25 0.30 0.375 0.50 0.625 0.75
SE1/SS1 Performance Limits
S1-8-424-G
1/80
1350 28W 3.2 300 263 190
S1-8-426-D 1550 39 W 3.7 310 282 232 190 140
S1-8-428-P 1/40 1650 53 W 3.9 329 303 266 237 214 149
S1-8-440-E 1/100 1050 50 W 1.5 311 224 127 101
S1-8-440-G 1/40 1350 55 W 3.5 400 354 257 189 174 138
S1-8-440-D 1/25 1550 75 W 4.9 459 420 351 308 256 198 167 115
S1-10-424-D 1/50 1550 45 W 4.6 575 526 462 407
S1-10-426-P 1/30
1650
55 W 4.8 590 551 502 468 429
S1-10-428-P 1/20 78 W 5.2 606 574 537 511 484 407 273 249 214
S1-10-440-E 1/40 1050 105 W 3.2 626 533 361
S1-10-440-G 1/20 1350 135 W 4.9 805 739 656 616 565
S1-10-440-D 1/12 1550 170 W 5.9 924 869 801 763 777 641
S1-12-426-D
1/10
1550 105 W 6.6 1113 1055 976 930 878 749 609 428
S1-12-436-G 1350 120 W 7.5 1269 1203 1101 1048 974 780 359
S1-12-432-E 1/20 1050 125 W 4.3 982 878 745 678 623 464 383
S1-12-432-G 1/12 1350 170 W 6.0 1262 1185 1098 1038 987 886 798 721 540
S1-12-432-D
1/8
1550 190 W 7.5 1449 1383 1309 1271 1225 1129 1042 953 861 615 478
S1-12-432-C8 860 0.03 4.0 804 664 512 438 349 249
S1-12-432-B6 1/6 1160 0.07 4.8 1084 991 872 816 755 660 503 431
S1-12-432-A4 1/4 1750 0.27 8.7 1636 1577 1515 1481 1447 1365 1282 1207 1085 947 706 585
S1-14-440-C8 1/8 860 0.07 5.9 1189 1055 919 711 649 551 408
S1-14-440-B6 1/6 1160 0.15 7.3 1604 1493 1406 1350 1297 1207 908 837 720
S1-14-432-A4 1/4
1750
0.29 12.9 2404 2351 2299 2273 2245 2189 2134 2052 1912 1636
S1-14-436-A3 1/3 0.39 14.8 2734 2674 2615 2585 2553 2487 2422 2340 2192 1829 1220
S1-16-436-C8 1/8 860 0.12 5.0 2003 1876 1732 1621 1433 1037 849 705
S1-16-426-B6
1/6
1160
0.15 7.5 2108 2027 1942 1894 1846 1725 1588
S1-16-428-B6 0.19 7.6 2235 2148 2058 2012 1964 1840 1710 1534 1126
S1-16-436-B4 1/4 0.29 9.5 2702 2609 2512 2461 2410 2281 2067 1761 1359 1049
S1-16-421-A3 1/3
1750
0.38 13.5 2552 2506 2461 2438 2415 2367 2309 2252 2143 1916
S1-16-428-A5 1/2 0.63 15.3 3372 3315 3257 3228 3199 3140 3078 3016 2908 2700 2468 1861
S1-16-436-A7 3/4 0.89 16.6 4076 4015 3954 3923 3892 3828
3760 3693 3591 3349 2902 2298
S1-18-434-C8 1/8
860
0.15 8.7 2661 2464 2202 2032 1874 1346
S1-18-436-C6
1/6
0.19 9.2 2778 2595 2319 2102 1963 1385 1108 912
S1-18-424-B6
1160
0.20 6.7 2800 2690 2568 2501 2427 2257 2025 1828
S1-18-429-B4 1/4 0.30 7.2 3238 3120 2987 2908 2828 2668 2434 2145 1510 1183
S1-18-436-B3 1/3 0.45 12.6 3747 3621 3466 3370 3267 3034 2732 2548 1727 1363
S1-18-424-A5 1/2
1750
0.67 15.7 4224 4151 4079 4043 4006 3925 3835 3745 3592 3252
S1-18-429-A7 3/4 0.88 17.4 4885 4807 4729 4690 4651 4565 4460 4354 4196 3926 3460 2984
S1-20-428-C6 1/6
860
0.19 10.8 3133 3001 2823 2727 2641 2390
S1-20-436-C4
1/4
0.29 11.7 3888 3717 3523 3420 3285 2918 2237 2091 1873
S1-20-424-B4
1160
0.30 13.8 3655 3561 3467 3419 3364 3255 3095 2924 2661
S1-20-428-B3 1/3 0.45 14.3 4227 4128 4030 3974 3901 3755 3621 3493 3175
S1-20-436-B5 1/2 0.70 14.4 5245 5118 4991 4926 4849 4697 4525 4321 3863 2920 2650
S1-20-420-A7 3/4
1750
0.87 24 4682 4617 4552 4519 4486 4421 4362 4303 4215 4036 3810
S1-20-428-A10 1 1.19 25 6377 6311 6246 6214 6181 6116 6050 5965 5820 5580 5368 5087
S1-20-432-A15 1
1
⁄2 1.73 26 7115 7038 6962 6924 6886 6809 6733 6653 6518 6292 6016 5688
S1-24-432-C4 1/4
860
0.34 9.1 5000 4767 4540 4409 4233 3789
S1-24-436-C3 1/3 0.41 10.0 5457 5232 5002
S1-24-437-C5
1/2
0.58 11.6 6136 5953 5764 5631 5497 5150 4720 4341
S1-24-428-B5
1160
0.61 14.1 5908 5794 5680 5623 5566 5382 5175 4898
S1-24-432-B7 3/4 0.83 14.7 6745 6572 6399 6313 6229 6064 5830 5569 5007
