Performance certified is for Models S2 for installation type A: free inlet, free outlet. Power rating (Bhp) does not include transmission losses. Performance ratings do not include
the effects of appurtenances (accessories). The sound ratings shown are loudness values in fan sones at 5 ft (1.5 m) in a hemispherical free field calculated per AMCA Standard 301.
Values are for installation type A: free inlet hemispherical sone levels.
Model Number
Motor
HP
Fan
RPM
Max
BHP
Sones
@ Free
Air
CFM / Static Pressure in Inches WG
0.00 0.10 0.125 0.15 0.20 0.25 0.30 0.375 0.50 0.625 0.75 1.00
SE2 / SS2 Performance Limits
S2-16-427-B6
1/6 1160
0.15 11.3 2213 1933 1849 1766 1536 1215 894
S2-16-435-B6 0.20 11.6 2522 2239 2150 2055 1732 1434
S2-16-417-A4 1/4
1750
0.30 18.7 2582 2414 2375 2336 2255 2156 2053 1869 1435 1084
S2-16-423-A3 1/3 0.38 19.9 3076 2899 2854 2809 2719 2621 2524 2331 1916 1362 1051
S2-16-430-A5 1/2 0.56 23 3531 3344 3297 3250 3155 3058 2944 2750 2303 1642 1223
S2-18-423-B6 1/6
1160
0.20 12.5 2917 2632 2562 2458 2249 2018 1727 1227
S2-18-430-B4 1/4 0.29 14.2 3376 3038 2944 2861 2662 2398 2084
S2-18-435-B3 1/3 0.35 16.2 3658 3311 3208 3089 2850 2556 1903
S2-18-411-A4 1/4
1750
0.30 21 3121 2978 2941 2893 2799 2697 2586 2415 2081 1883 1251
S2-18-415-A3 1/3 0.41 22 3623 3476 3439 3400 3300 3199 3091 2920
S2-18-421-A5 1/2 0.59 22 4177 4015 3975 3931 3807 3683 3574 3416 3059 2558 2134
S2-20-420-B6 1/6
1160
0.21 15.3 3697 3350 3257 3137 2857 2532 2155 1739
S2-20-423-B4 1/4 0.30 17.2 3997 3626 3522 3419 3153 2834 2430
S2-20-430-B3
1/3
0.40 18.6 4468 4087 3989 3882 3626 3281
S2-20-407-A4
1750
0.37 27 3579 3382 3333 3282 3180 3053 2922 2744 2300 1869 1342
S2-20-410-A3 0.37 28 4035 3835 3785 3731 3623 3461 3254 3113 2791
S2-20-415-A5 1/2 0.57 29 4934 4697 4637 4578 4454 4330 4185 3957 3572 3066
S2-20-420-A7 3/4 0.88 30 5577 5355 5300 5243 5121 4999 4877 4614 4138 3544 2992
S2-20-427-A10 1 1.19 33 6633 6364 6297 6231 6099 5968 5837 5613 5179 4614 3812
S2-20-435-A15 1
1
⁄2 1.76 35 7266 6980 6909 6837 6691 6543 6396 6115 5453 4658
S2-24-615-C4 1/4
860
0.28 15.7 4687 4200 4058 3895 3561 3126 2488
S2-24-620-C3 1/3 0.36 18.5 5300 4710 4557 4410 3993 3445 2607
S2-24-630-C5 1/2 0.54 18.8 6439 5768 5599 5412 4993 4387
S2-24-620-B7 3/4
1160
0.86 23 7148 6728 6619 6502 6268 6049 5831 5308 4315
S2-24-625-B10 1 1.13 25 7917 7491 7391 7291 7060 6781 6501 6035 4850 2745
S2-24-600-A7 3/4
1750
0.87 36 5070 4877 4828 4778 4676 4573 4455 4251 3911 3518 3161 2287
S2-24-604-A10 1 1.18 39 6297 6081 6027 5973 5865 5747 5627 5447 5084 4671 4203 3223
S2-24-610-A15 1
1
⁄2 1.70 40 8137 7904 7845 7787 7670 7559 7448 7281 6968 6571 6178 5106
S2-24-615-A20 2 2.28 41 9537 9310 9253 9197 9083 8961 8835 8646 8315 7915 7508 6559
S2-30-618-C7 3/4
860
0.79 23 9698 9066 8886 8707 8309 7892 7340 6370
S2-30-625-C10 1 1.18 28 11515 10823 10644 10461 10097 9629 9051 7945 5213
S2-30-635-C15 1
1
⁄2 1.80 32 13290 12505 12291 12076 11647 11060 10192 7951
S2-30-605-B7 3/4
1160
0.86 29 7911 7479 7369 7257 7034 6795 6551 6210 5496 4497 3377
S2-30-610-B10 1 1.17 30 9662 9293 9201 9103 8872 8640 8392 7976 7204 6248 5108
S2-30-615-B15 1
1
⁄2 1.72 31 12000 11565 11456 11348 11130 10890 10619 10200 9404 8327 6921
S2-30-620-B20 2 2.29 33 13905 13434 13316 13198 12939 12665 12391 11954 11144 10136 8640
S2-36-607-C7 3/4
860
0.82 27 9985 9347 9183 9012 8669 8255 7829 7039 5325 3679 2486
S2-36-611-C10 1 1.11 30 12131 11529 11360 11187 10840 10449 10058 9289 7622 5532 3782
S2-36-617-C15 1
1
⁄2 1.61 31 15162 14491 14324 14153 13810 13442 12926 12117 10512 7704 5270
S2-36-600-B10 1
1160
1.21 34 8200 7791 7656 7515 7224 6913 6617 6214 5478 4679 3902
S2-36-605-B15 1
1
⁄2 1.72 36 11977 11535 11424 11313 11077 10828 10580 10147 9384 8487 7337 5080
S2-36-609-B20 2 2.34 37 14957 14468 14345 14223 13976 13728 13480 13098 12411 11537 10483 7678
S2-36-614-B30 3 3.29 40 18400 17945 17832 17718 17490 17263 16965 16517 15787 15003 13722 10993
S2-42-602-C10 1
860
1.08 30 8673 7991 7811 7632 7254 6888 6531 5979 4937 3944 2850
S2-42-608-C15 1
1
⁄2 1.73 32 14642 14035 13883 13732 13396 13058 12692 12072 10980 9558 8035 4540
S2-42-612-C20 2 2.42 33 18363 17675 17503 17331 16966 16600 16233 15619 14477 13041 11303 6625
S2-42-617-C30 3 3.32 35 21840 21148 20975 20802 20440 20032 19624 18975 17694 16259 14629 8191
S2-42-627-C50 5 5.95 41 28811 27924 27702 27480 27037 26533 26023 25261 24002 22494 20376 13589
S2-48-407-C15 1
1
⁄2
860
1.84 43 18124 17081 16823 16565 16049 15499 14820 13815 12067 9984 7536
S2-48-410-C20 2 2.40 44 21801 20853 20616 20362 19848 19333 18699 17684 15807 13843 11719
S2-48-415-C30 3 3.58 48 27004 26027 25783 25539 24915 24272 23638 22726 21025 19172 16924
S2-48-422-C50 5 5.91 53 34332 33166 32874 32583 31944 31257 30570 29594 27990 25869 23518
S2-54-420-F50
5
690 5.76 52 41542 39736 39284 38845 38011 37177 36322
34995 32089 28911 25289 14535
S2-54-410-C50
860
5.68 53 35642 34502 34217 33932 33364 32826 32287 31334 29690 27722 25548 20120
S2-54-416-C75 7
1
⁄2 8.68 54 45612 44465 44179 43892 43319 42745 42051 40967 39103 37130 34973 30171
S2-Direct Drive - Level 2
