39
Page Header
Model Number
Motor
HP
Fan
RPM
Max
BHP
*Sones
CFM / Static Pressure in Inches WG
0.00 0.10 0.125 0.15 0.20 0.25 0.30 0.375 0.50 0.625 0.75 1.00
48 Performance Max RPM L - 908 H - 1182 Max Motor Frame Size - 215T TS = RPM x 12.566
SBC-3L48-15 1
1
⁄2
435 0.99 18.5 21897 17413 15801
500 1.51 23 25169 21295 20354 19165
531 1.80 24 26730 23117 22183 21212
SBC-3H48-15 1
1
⁄2
566 0.99 23 21010 18533 17717 17010 15233 13144 9229
650 1.50 28 24128 21973 21464 20750 19481 17983 16242 12200
691 1.80 31 25650 23608 23130 22600 21313 20083 18535 15959
SBC-3L48-20 2
550 2.00 25 27686 24227 23288 22434
585 2.41 27 29448 26249 25335 24494 22640
SBC-3H48-20 2
716 2.01 33 26578 24598 24136 23675 22413 21279 19918 17513
761 2.41 35 28249 26368 25935 25501 24434 23316 22195 20084 15370
SBC-3L48-30 3
630 3.01 30 31713 28809 27962 27113 25587 23623
669 3.61 32 33676 30972 30203 29404 27904 26301
SBC-3H48-30 3
819 3.00 39 30402 28632 28231 27827 27020 25867 24889 23274 19744 13540
871 3.61 43 32332 30648 30270 29892 29133 28230 27191 25779 22761 19268
SBC-3L48-50 5
746 5.00 38 37552 35186 34519 33835 32401 31082 29675
793 6.01 41 39918 37729 37102 36474 35144 33810 32626 30464
SBC-3H48-50 5
971 5.00 53 36044 34496 34157 33818 33140 32459 31682 30277 28102 25291 22178
1032 6.00 59 38308 36841 36509 36191 35553 34913 34272 33002 30995 28669 25923 16703
SBC-3L48-75 7
1
⁄2
854 7.50 45 42989 41003 40421 39838 38648 37395 36190 34476
908 9.02 50 45707 43860 43334 42786 41690 40528 39350 37736 34664
SBC-3H48-75 7
1
⁄2
1112 7.51 67 41278 39917 39577 39282 38690 38098 37504 36601 34556 32687 30384 25026
1182 9.01 75 43876 42596 42275 41971 41415 40859 40300 39461 37668 35918 34068 29382
54 Performance Max RPM L - 727 H - 856 Max Motor Frame Size - 254T TS = RPM x 14.135
SBC-3L54-20 2
364 1.51 18.0 25482 21713 20664 19377
400 2.01 20 28002 24618 23706 22752 19950
425 2.41 22 29752 26685 25741 24882 22822
SBC-3H54-20 2
429 1.51 21 25150 22604 21870 21035 19310 17043 13521
471 2.00 23 27612 25349 24701 24032 22511 20907 18781
501 2.41 26 29370 27282 26674 26066 24696 23254 21708 18049
SBC-3L54-30 3
458 3.01 25 32062 29480 28382 27585 25914 23719
487 3.62 28 34092 31897 30843 29919 28420 26637 24050
SBC-3H54-30 3
539 3.00 29 31598 29657 29143 28577 27407 26078 24712 22298
573 3.61 31 33591 31765 31309 30796 29731 28536 27286
25299 20153
SBC-3L54-50 5
543 5.02 33 38013 36203 35539 34594 32996 31652 30072 26691
577 6.02 38 40393 38690 38264 37449 35716 34451 33186 30778
SBC-3H54-50 5
639 5.00 37 37461 35823 35414 35004 34086 33131 32068 30386 27398 22327
680 6.02 41 39864 38325 37941 37556 36748 35851 34954 33382 30664 27125 21725
SBC-3L54-75 7
1
⁄2
621 7.51 44 43473 41891 41495 41090 39437 38008 36833 34916 30021
660 9.01 49 46203 44715 44342 43970 42720 41165 40006 38347 34940
SBC-3H54-75 7
1
⁄2
732 7.52 47 42913 41483 41126 40768 40054 39254 38421 37100 34654 32044 28344
778 9.03 53 45609 44264 43928 43592 42919 42229 41445 40269 38025 35671 33163 23604
SBC-3L54-100 10
684 10.03 53 47883 46447 46088 45729 44718 43217 41935 40334 37224 30947
727 12.00 61 50894 49542 49204 48866 48191 46850 45438 43846 41235 37872
SBC-3H54-100 10
805 10.02 55 47192 45892 45567 45242 44592 43942 43205 42068 39973 37748 35353 27829
856 12.03 61 50182 48959 48654 48348 47737 47126 46501 45432 43599 41507 39367 33873
CFM values shown
in black are the most
efficient selections.
Values shown in gray
are not recommended.
Performance certified is for Model SBC for installation type A: free inlet, free outlet. Power rating (Bhp) does not include transmission losses. Performance ratings do not include
the effects of appurtenances (accessories). The sound ratings shown are loudness values in fan sones at 5 ft (1.5 m) in a hemispherical free field calculated per AMCA Standard 301.
Values are for installation type A: free inlet hemispherical sone levels.*Sones shown apply to the highest cataloged CFM in black type at each fan RPM. For selections at other CFM and static
pressure points,refer to CAPS, the Computer Aided Product Selection Program.
SBC-48-54 Belt Drive
Cast Aluminum
