13
OPERATION
W A R N I N G
To avoid injury:
• Do not squeeze the trigger while the grass trimmer/edger is inverted.
Do not carry the grass trimmer/edger with your finger on the switch. Avoid unintentional starting.
To Turn On/Off: (
See Figure 7.)
1. Press the safety lock out button (2) and squeeze the trigger switch (1) to start.
2. Release the trigger switch (1) to stop.
C A U T I O N
Always allow 5 seconds or more for the cutting linespool to stop rotating after releasing the
trigger switch.Do not invert the grass trimmer/edger , or place your handsunder the protective
guarduntil the grass trimmer/edger spool has come to a complete stop.
Fig. 7
Edging Function (
See Figure 8.)
For use next to patios, driveways and walkways or any areas requiring a well groomed edge line.
1. Push on the edge button and tilt the trimmer head 90 degrees until the head locks into position
and release button.
IMPORTANT:
The battery must be removed before making adjustments.
Lengthening the Line (
See Figure 9.)
While the grass trimmer/edger is operating, the cutting line gets worn down and becomes
shorter. This trimmer is equipped with Automatic Line Advancement which automatically feeds
,ecnavda yllacitamotua ton seod enil eht fI.nwod sraew ti sa htgnel tcerroc eht ot enil lanoitidda
the trimmer line may be tangled or empty. To advance the line, stop and restart the trimmer.
Upon starting, the line will automatically advance 1/4" (6.4 mm) .
Fig. 8
1
2
