GreenWorks CSF401 User Manual

1 DESCRIPTION
1.1 PURPOSE
This chainsaw is designed for cutting branches, trunks,
logs and beams of a diameter determined by the cutting
length of the guide bar. It is only designed to cut wood.
It is only to be used in an outdoor, domestic application
by adults.
Do not use the chainsaw for any purpose not listed
above.
This chainsaw is not to be used for professional tree
services. It is not to be used by children or by persons
not wearing adequate personal protective equipment
and clothing.
1.2 OVERVIEW
Figure 1-22
1
Guide bar cover
2
Front handle guard / chain brake
3
Front handle
4
On/off switch
5
Lock out button
6
Trigger
7
Oil indicator
8
Oil tank cap
9
Saw chain
10
Guide bar
11
Rear handle
12
Spike bumpers
13
Chain tension knob
14
Chain cover
15
Chain cover knob
16
Bolt for saw chain tension
17
Sprocket
18
Bar guide
19
Oil outlet
20
Bar groove
21
Chain drive links
22
Cutter
23
Felling direction
24
Danger zone
25
Escape route
26
Direction of fall
27
Notch
28
Felling back cut
29
Hinge
30
Limb cut
31
Keep work off ground leave support limbs until
log is cut
32
Log supported along the entire length
33
Cut from top (over buck) avoid cutting earth
34
Log supported one end
35
Under buck
36
Over buck
37
Log supported both ends
38
Bucking a log
39
Stand on uphill side when cutting because log
may roll
2 SAFETY
WARNING
Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Do not change or make accessories that are not
recommended by the manufacturer.
WARNING
Do not put in the battery pack until you assemble all
the parts.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts have damage, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
3.2 ASSEMBLE THE GUIDE BAR AND
THE CHAIN
Figure 1-7
5
English
EN
