5.4 ADD THE BAR AND CHAIN
LUBRICANT
Examine the amount of oil in the machine. If the oil level
is low, add the bar and chain lubricant as follows.
IMPORTANT
Use bar and chain lubricant that is only for chains and
chain oilers.
NOTE
The machine comes from the factory without bar and
chain lubricant.
1. Loosen and remove the cap from the oil tank.
2. Put the oil into the oil tank.
3. Monitor the oil indicator to make sure that no dirt in
the oil tank while you add the oil.
4. Put the oil cap on.
5. Tighten the oil cap.
6. The whole oil tank will last for 15 - 40 minutes.
IMPORTANT
Do not use dirty, used or contaminated oil. Damage
can occur to the bar or chain.
6 TRANSPORTATION AND
STORAGE
Before you move the machine, always
• Remove the battery pack from the machine.
• Keep hands clear of the lock-out button.
• Put the scabbard on the guide bar and the chain.
Before you put the machine into storage, always
• Remove all residual oil from the machine.
• Remove the battery pack from the machine.
• Clean all unwanted material from the machine.
• Make sure that the storage area is
• Not available to children.
• Away from agents which can cause corrosion,
such as garden chemicals and de-icing salts.
7 TROUBLESHOOTING
Problem Possible cause Solution
The guide bar
and the chain
become hot and
release smoke.
The chain is too
tight.
Adjust the chain
tension.
The oil tank is
empty.
Add lubricants.
Contamination
causes a block-
age of the dis-
charge port.
Remove the
guide bar and
clean the dis-
charge port.
Contamination
causes a block-
age of the oil
tank.
Clean the oil
tank. Add new
lubricant.
Contamination
causes a block-
age of the guide
bar and the oil
tank cap.
Clean the guide
bar and the oil
tank cap.
Contamination
causes a block-
age of the
sprocket or
guide wheels.
Clean the
sprocket and the
guide wheels.
The motor runs
but the chain
does not rotate.
The chain is too
tight.
Adjust the chain
tension.
The guide bar
and the chain
are damaged.
Replace the
guide bar and
the chain if it is
necessary.
The motor is
damaged.
1. Remove the
battery pack
from the ma-
chine.
2. Remove the
guide bar
cover.
3. Remove the
bar and saw
chain.
4. Clean the
machine.
5. Install battery
pack and op-
erate the ma-
chine.
If the sprocket
rotates, it means
the motor works
properly. If not,
call service cen-
ter.
9
English
EN
