Chapter 1 Overview
1. Composition
As shown in Figure 1-1, the CA-10 module is divided into 10 parts depending on their
functions:
1) Input slot;
2) Note validator;
3) Thickness assembly;
4) Lower transport;
5) Diverter;
6) Reject slot;
7) Escrow slot;
8) External shutter;
9) Output slot;
10) Internal shutter
11) Pressure plate;
12) Connection port;
1
2
3
12
6
7
8
9
5
4
1011
Figure 1-1
