Scope of supply
Pos. Qty. Designation Pos. Qty. Designation
1 1 Warming rack 15 1 Wheel leg
2 2 Cooking grill 16 2 Leg cap
3 3 Flame tamer 17 1 Front panel
4 1 Lid handle 18 1 Wheel axle
5 1 Thermometer 19 2 Wheel
6 1 Burner unit, pre-assembled 20 2 Wheel cap
7 3 Flame regulator 21 1 Hose holder
8 1 Side shelf, left
9 1 Tool holder
10 1 Side shelf, right
11 1 Grease tray
12 1 Grease tray holder
13 2 Cross bar
14 1 Leg
2x
M6x15
1x
M6x16
26x
M10
2x
Ø6,5x18
8x
A
B C
D
E
Ø6,2
8x
F
