GRILLCHEF
Assembly procedure
Assembly step 1
• Screw the left and right wheel legs (10) to the base
of the cart (16) using M6x60 bolts, Ø6 washers and
M6 nuts. When doing this always make sure that two
identical legs (10) are used for the left and right side
(see illustration).
Assembly step 2
• Secure the rear panel (11) between the wheel legs
(10) using M6x10 bolts.
16
10
10
11
10
10
