Baserunner Controller User Manual
Rev 1.0
The LED may also flash several different warning codes. These warnings do not
stop the controller from running and will appear as various limits are reached in
normal operation, they are not usually a cause for any concern.
Table 3: Baserunner LED Warning Flash Codes
5-1 Communication Timeout
5-2 Hall Sensor
5-3 Hall Stall
5-4 Wheel Speed Sensor
5-5 CAN Bus
5-6 Hall Illegal Sector
5-7 Hall Illegal Transition
5-8 Low Voltage Rollback Active
6-1 Max Regen Voltage Rollback Active
6-2 Motor Overtemperature Rollback
6-3 Controller Overtemperature Rollback
6-4 Low SOC Foldback
6-5 Hi SOC Foldback
6-6 I2tFLDBK
6-7 Reserved
6-8 Throttle fault converted to warning
-25-
