Baserunner Controller User Manual
Rev 1.0
8 LED Flash Codes
The embedded LED on the side of the controller provides a useful status
indicator. It will flash according to the following table if the controller detects any
faults. Some faults will clear automatically once the condition clears, such as
“Throttle Voltage Outside of Range,” while other faults may require turning the
controller off and on.
Table 2: Baserunner LED Fault Flash Codes
1-1 Controller Over Voltage
1-2 Phase Over Current
1-3 Current Sensor Calibration
1-4 Current Sensor Over Current
1-5 Controller Over Temperature
1-6 Motor Hall Sensor Fault
1-7 Controller Under Voltage
1-8 POST Static Gate Test Outside Range
2-1 Network Communications Timeout
2-2 Instantaneous Phase Over Current
2-3 Motor Over Temperature
2-4 Throttle Voltage Outside of Range
2-5 Instantaneous Controller Over Voltage
2-6 Internal Error
2-7 POST Dynamic Gate Test Outside Range
2-8 Instantaneous Controller Under Voltage
3-1 Parameter CRC Error
3-2 Current Scaling Error
3-3 Voltage Scaling Error
3-4 Headlight Under Voltage
3-5 Torque Sensor
3-6 CAN Bus
3-7 Hall Stall
4-1 Parameter2CRC
-24-
