Grizzly DEEP DIGGER User Manual

17
Specications are subject to change without prior notication December 2019
8Specications
Size Nm ft/lb Size Nm ft/lb Size Nm ft/lb Size Nm ft/lb
M20 240 180 M5 4.2 3.7 M5 6.7 5.9 1/2" 125 92
M24 425 310 M6 7.6 6.7 M6 10.9 9.7 M18 475 350
M30 750 553 M8 18.5 16.4 M8 26.9 23.8 M20 570 420
M10 37.0 32.7 M10 52.9 46.8
M12 64.7 57.2 M12 91.6 81 Size Nm ft/lb
M16 160 141 M16 227 201 M16 122 91
M20 312 277 M20 444 393 M20 270 200
M24 538 476 M24 750 664
HYD
¾" JIC 53 39 M30 750 664 M30 750 664 M20 HT 420 310
Reference: 'Thomas Warburton - Pocket Fastener Guide' Page 49
20%
Integrated Management System
pc 5.5 or Tapped Thread
PC 10.9
pc
8.8
dry thread, zinc course
pc 10.9 dry thread, zinc course
wheel nuts lubed
gang bolts lubed
WI 09J TORQUE CHART
Work Instruction
Rev 8 / 20 May 19 Q:\Quality_System\Work Instructions & Safe Work Procedures\WI Work Instructions\WI 09J TORQUE CHART 1
Bolt Torque Chart
Current Tyre
Size
Model Ply Pressure
kpa psi
11.5/80 - 15.3
Deep
Digger 14 496 72
