Grizzly DEEP DIGGER - Specifications; Model Specifications

16
Specications are subject to change without prior notication From serial number 7027
8Specications
Grizzly Recommended Retail Price List Effective from 1
st
July 2019
Copyright 2019
*prices and specifications are subject to change without prior notice / Weights indicated are with most common options
11
DEEP DIGGER – Sub Soil Ripper
MODEL RL001 RL003 RL005 RL007 RT007 RT009 RT011 RT015
RRP EX GST
INCL GST PRICE
$5,450
$5,995
$11,450
$12,595
20,100
$22,110
$26,450
$29,095
$52,800
$58,080
$61,100
$67,210
$69,200
$76,120
$140,700
$154,770
Draught kW
(hp) Required
approx
22-40
(30-50)
50-90 (70-
120)
90-150
(120-200)
220-260
(300-350)
220-260
(300-350)
260-330
(350-450)
300-370
(400-500)
370+
(500+)
Tine Spacing N/A 500mm (20”)
Weight kg
approx
300 650 950 1700 2605 3100 3460 12,600
Width of Cut - 1m 2m 3m 3m 4m 5m 7m
Effective
Working Width
0.5m
(1’7”)
1.5m
(4’11”)
2.5m
(8’2”)
3.5m
(11’6”)
3.5m
(11’6”)
4.5m
(14’9”)
5.5m
(18’) - SEE
OPTIONS
7.5m
(24’7”)
Frame Width
(Transport
width)
1.2m
(3’10”)
1.2m
(3’9”)
2.2m
(7’)
3.2m
(10’5”)
3.2m
(10’5”)
4.1m
(13’7”)
5.2m
(17’1”)
3.5m (11’6”)
Folding
Wing
Tyres N/A
Recommended Optional
Depth Control Wheels
(11.5/80 - 15.3) 14 PR, dual rocker
wheel assembly (4 tyres in total)
385/65R
22.5 Super
Singles, dual
rockers
Hitch/Pull Size
*HEAVY DUTY
CAT 3 / 4* CAT
2/3 –
Se e Options
CAT 3 CAT 3 150 x 100 x 9mm RHS
150 x 150 x
9mm RHS
Main Frame
Size
100 x 100 x 9mm RHS
150 x 100 x 9mm RHS
150 x 150 x
9mm RHS
Hydraulic Pitch
Control
N / A
4” x 8”
5” x 12” 5” x 12”
Phasing Rams (5” x 12”) & (4.5” x 12”)
(5” x 18”) &
(5.5” x 18”)
Pull Tongue Articulated Hitch CAT 4 – See Options
Tine Size
710mm (28”) long x 32mm (1 ¼”) thick – maximum working depth 660mm (26”) – See Options
Tine and Point
32mm hardened steel plate with replaceable hard faced wear boot and replaceable point.
–
See Options
Shear Pins
25mm with 15mm / 18mm shear points. [12 tonne breakout]
OPTIONS
MODEL
RL001
RL003
RL005
RL007
RT007
RT009
RT011
RT015
Manual Crumble
Roller
N/A
$6,100
$6,710
$8,190
$9,009
$8,190
$9,009
$11,450
$12,595
$12,360
$13,596
N/A
Hydraulic
Crumble Roller
*Rollers Add .5mtr
to transport width
$5,890
$6,479
400kgs
$8,400
$9,240
600kgs
$10,540
$11,594
700kgs
$10,540
$11,594
700kgs
$13,810
$15,191
800kgs
$14,720
$16,192
900kgs
Standard
with roller
Hydraulic Depth
Wheels
N/A
(7.50 x 16) 8 PR
$6,500 $7,150
Transport wheels standard act as depth wheels
Pipe Laying
Attachment
Poly up to 2” with
fitting $800 $880
RT015 ONLY has option for 100mm longer tine. $7,500 $8,250
Pull Tongues N/A Articulated Hitch CAT 3 or 5 –
See Page 21
Hard Facing
Hard Faced point $65 $71.50 per point
CTF Tine
Spacing
*AVAILABLE ON RT011 ONLY* Tine spacing becomes 550mm meaning overall effective working width is
6m to suit 12m Controlled Traffic applications – ADDS 0.5m to width of frame and roller – ADD $3,000 $3,300
Tungsten Tile
Tungsten Tile Point $200 $220 per point (not recommend in rocky conditions)
Single Tine to
suit CAT 2 / 3
Single Tine CAT 2 / 3 (RL001 ONLY) for smaller tractors (less then 130hp) – RRP $4,800 $5,280
