13 Parts
DESCRIPTIONPART NO.QTY
ITEM
GE50 RADIAL SPHERICAL PLAINBDGAA00141
GREASE NIPPLE 1/4" UNF
BMAAA00082
GREASE NIPPLE 1/8 BSP
BMCAA00023
DEPTH GAUGE CABSE131
14
DEPTH GAUGE CABSE131A15
BEARING HOUSING - 3 BOLTCDEUU00046
TOOL BOX LID 3mmCGBEE003A17
WEAR BOOT HARD FACED - DEEP DIGGERDYSPB50088
BOLT M8 X 20 FABEA02039
BOLT M8 X 45FABEA0451910
BOLT M 8 X80FABEA080111
BOLT M12 X 75 PC 8.8FABGA075212
BOLT M16 X 40 PC 8.8FABHA040213
BOLT M20 X 55 pc 8.8 COARSEFABJA0551214
BOLT M20 X 180 pc 8.8 COARSEFABJA180215
BOLT M24 X 110FABKA110816
NYLOC NUT M8 P TYPEFFBEA0001117
NYLOC NUT M12 P TYPEFFBGA000218
NYLOC NUT M20 P TYPE 2.5FFBJA000219
NYLOC NUT M24 P TYPEFFBKA000720
WHEEL NUT 18mm - (30mm AF)FFFJA0302421
PIN 1" RIPPER SHEAR PIN (15mm)
FGBKA094A1422
ROLL PIN 8 X 50FGCBA0502123
PIN CAT 3 LOWER 1" 7/16 x 8" CAPTIVEFGFRA200T224
LYNCH PIN 6mmFKAEA000125
LYNCH PIN 7/16" strong clip!FKAKA000226
M8 WASHER 5/16"F436 HARD ZYP
FMCEE0001127
M12 WASHER 1/2" type 1HARD ZYP
FMCGE0004
28
M24 WASHER F436 HARD ZYPFMCMG000
15
29
LOCK WASHER,20id x 40od x 1.5FMFJBF001230
7 TYNE TRAILING RIPPER FRAMEGCN007H131
HYDRAULIC KIT- DEEP DIGGER -7 TRAILINGGHPC0007132
RIPPER TYNE 700mm UNDER FRAME BIS 80GNAFM502733
DEPTH GAUGE POINTERGNBEN005
1
34
BOLT KIT - FIELD BOSS SPLITGSFM0003S135
TRANSPORT BLOCK (290mm x 1.5")HRDAA290236
PIN RETAINER BUSHMDAYA014237
ROCKER AXLE SPACERMFAAA100238
GRIZZLY BLUE SPRAY CAN 300gramPAAGA300
1
39
SHUT THE GATE SIGNPD000082140
DECAL KIT RIPPER TRAILINGPDAER001141
SOCKET 30mm.3/4" DRIVE
TDASC000142
3/4" DRIVE 200mm EXTENSION
TDGAA200143
L HANDLE 3/4" DRIVETDGAC000
144
ROLL PIN PUNCH 5/16"TGA80050
145
ROCKER AXLE ASSEMBLY H70 / 13.0 X 65 - 18WMMDA450246
DOCUMENT HOLDERXBCDOC235147
7 TYNE TRAILING ASSY KIT DEEP
DIGGER
L:\Inventor\Parts\GS-\GSN70000HB.idw
GSN70000HB
35
21
46
47
9
10
16
34
10
11
10
46
10
17
38
33
8
23
4
5
