Grizzly DEEP DIGGER - Hydraulic Kit- Deep Digger -7 Trailing

45
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
RETRACT LINE RELIEF VALVE KITHFALL50-B
11
HOSE 3/8 DB (2800) QR 1/2" BSP FEMALE
3/4UNO MALE
HGCZC800B22
HYD HOSE 3/8" E26 (3200) QRHGCZD200Q13
HYD HOSE 3/8" E26 (3300) QRHGCZD300Q1
4
HYD HOSE 3/8" E26 (4100)HGCZE100A
15
HYD HOSE 3/8" E26 (4300)
HGCZE300A16
HYD HOSE 3/8" E26 (4800)HGCZE800A17
ELBOW 3/4 JICM 3/4 UN O MALEHHABAM0748
ELBOW RESTRICTOR3/4 JICM 3/4 UN ORINGHHABAM07A29
HYD Coupling COVER BLUE
HHZWUA07B
2
10
HYD Coupling COVER RED
HHZWUA07R211
20mm DOUBLE HOSE CLAMP SHELLHJBCA0001312
TOP PLATE DOUBLE FOR GROUP 3HJBFA0001213
DEPTH STOP - CAPTIVE PAIRHMDEA004
114
HEAT SHRINK RED - WHEEL LIFTHXEAF000115
HEAT SHRINK BLUE- PITCH CONTROLHXECF000116
HYD. CYL. 4 X 8 1.75 RODHYP400/08117
HYD. CYL. 4.75 X 12 DS 1.5" SHAFTHZP475/12D118
HYD CYL 5" X 12" D/S 1.5" RODHZP500/12D
1
19
HYDRAULIC KIT- DEEP DIGGER -7
TRAILING
L:\Inventor\Parts\GH-\GHPC0007.idw
18
19
14
6
5
8
13
7
6
8
8
7
5
1
2
2
3
4
9
9
17
11
16
GHPC0007
