Grizzly G0441 User Manual

-14-
Model G0440/G0441 (Mfg. Since 03/12)
G0440 Inventory
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Inventory (Figure 2) Qty
A. Intake Cylinder ........................................... 1
B. Cyclone Funnel .......................................... 1
C. Intake Barrel ............................................... 1
D. Canister/Drum Collection Bags .........1 Each
E. Gray Flexible Hose 7" X 32" ...................... 1
F. Motor/Blower Housing Assembly ............... 1
G. Collection Drum Lid .................................... 1
H. Collection Drum .......................................... 1
I. Collection Drum Seal ................................. 1
J. Clear Flexible Hose 9" x 8" ........................ 1
K. Hose Clamps 9" ......................................... 2
L. Outlet Port .................................................. 1
M. Filter L-Braces ............................................ 2
N. Foam Tape Roll 3 x 6mm .......................... 1
O. Hose Clamps 7" ......................................... 3
P. Hardware Box
—Phillips Head Screws #10-24 x
3
⁄8" .......... 6
—Hex Nuts #10-24 ..................................... 6
—Drum Latches ......................................... 3
—Roll of Foam Tape 3 x 15mm ................. 1
Q. Hardware Box
—Hex Bolts
5
⁄16"-18 x 1" ............................ 22
—Hex Bolts
5
⁄16"-18 x
3
⁄4" ........................... 24
—Flat Washers
5
⁄16" .................................. 64
—Fender Washers
5
⁄16" ............................... 4
—Hex Nuts
5
⁄16"-18 .................................... 22
R. Hardware Box
—Casters ................................................... 4
—Hex Nuts
3
⁄8"-16 ....................................... 4
—Lock Washers
3
⁄8" .................................... 4
—Flat Washers
3
⁄8" ..................................... 8
S. Wall Mount Brace ....................................... 1
T. Barrel Gaskets ............................................ 2
U. Brace Gaskets ............................................ 2
V. Outlet Gasket ............................................. 1
W. Canister Filter Assembly ............................ 1
X. Hose Clamps 1
1
⁄4" ...................................... 2
Y. Vacuum Hose 1
1
⁄4" x 98" ............................ 1
Z. Collection Drum Vacuum Ring ................... 1
AA. Cyclone Vacuum Tube ............................... 1
F
C
B
A
D
E
L
J
I
G
H
N
Q
P
R
S
T
U
V
Figure 2. Model G0440 inventory.
K
M
O
W
X
Y
Z
AA
