Model G0440/G0441 (Mfg. Since 03/12)
-47-
G0440 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0440001 MOTOR 2HP 220V 1-PH 39 P0440039 BARREL GASKET 584MM DIA.
1-1 P0440001-1 MOTOR FAN COVER 40 P0440040 INTAKE BARREL 20"
1-2 P0440001-2 MOTOR FAN 41 P0440041 HEX BOLT 5/16-18 X 3/4
1-3 P0440001-3 CAPACITOR COVER 42 P0440042 FLAT WASHER 5/16
1-4 P0440001-4 S CAPACITOR 300M 125V 1-3/4 X 3-3/8 43 P0440043 BARREL GASKET 584MM DIA.
1-5 P0440001-5 R CAPACITOR 50M 250V 1-5/8 X 3-1/2 44V2 P0440044V2 CYCLONE FUNNEL 20" V2.08.10
1-6 P0440001-6 JUNCTION BOX 45 P0440045 HEX BOLT 5/16-18 X 1
1-7 P0440001-7 BALL BEARING 6205ZZ 46 P0440046 FLAT WASHER 5/16
1-8 P0440001-8 BALL BEARING 6203ZZ 47 P0440047 HEX NUT 5/16-18
1-9 P0440001-9 CONTACT PLATE 48 P0440048 HOSE CLAMP 9"
1-10 P0440001-10 CENTRIFUGAL SWITCH 3450 49 P0440049 CLEAR FLEX PIPE 9" x 200MM
2 P0440002 MOTOR CORD 12G 3C 50 P0440050 COLLECTION DRUM LID V2.08.06
3V3 P0440003V3 REMOTE MAG SWITCH 220V V3.01.12 51V2 P0440051V2 DRUM SEAL TYPE-T 2.1M V2.11.09
3V3-1 P0440003V3-1 CONTACTOR NHD C-12D 220V 52V2A P0440052V2A COLLECTION DRUM ASSY 35GAL V2.08.10
3V3-2 P0440003V3-2 OL RELAY NHD NTH-14 11-14A 52V2 P0440052V2 COLLECTION DRUM 35GAL V2.08.10
3V3-3 P0440003V3-3 CIRCUIT BOARD 220V W/TRANSFORMER 53 P0440053 DRUM LID LATCH ASSEMBLY
3V3-4 P0440003V3-4 ON/OFF SWITCH 110V/220V 54 P0440054 PHLP HD SCR 10-24 X 3/8
4 P0440004 REMOTE CONTROLLER 55 P0440055 HEX NUT 10-24
5 P0440005 HEX BOLT 3/8-16 X 1-1/2 56 P0440056 CASTER 2"
6 P0440006 FLAT WASHER 3/8 57 P0440057 HEX NUT 3/8-16
7 P0440007 LOCK WASHER 3/8 58 P0440058 LOCK WASHER 3/8
8 P0440008 HEX NUT 3/8-16 59 P0440059 FLAT WASHER 3/8
9 P0440009 BLOWER COVER 60 P0440060 HEX BOLT 5/16-18 X 1
10 P0440010 HEX BOLT 3/8-16 X 1 61 P0440061 FLAT WASHER 5/16
11 P0440011 FENDER WASHER 3/8 62V2 P0440062V2 SWITCH MOUNTING BRACKET V2.01.12
12 P0440012 LOCK WASHER 3/8 63 P0440063 HEX NUT 5/16-18
13 P0440013 HEX NUT 3/8-16 64 P0440064 WALL MOUNTING BRACE
14A P0440014A IMPELLER 14-1/2" V2.02.06 65 P0440065 MOTOR SPEC LABEL
15 P0440015 IMPELLER FENDER WASHER 3/8 66 P0440066 MOTOR WARNING LABEL
16 P0440016 HEX BOLT 3/8-16 X 1 LH 67 P0440067 GLASSES/RESPIRATOR LABEL
17 P0440017 FOAM TAPE 3 X 6 X 1600MM 68 P0440068 READ MANUAL LABEL
18V2 P0440018V2 BLOWER HOUSING 14.5" IMP V2.02.06 69 P0440069 HANDS/INLET LABEL
19 P0440019 FLAT WASHER 5/16 70 P0440070 RETURN RED HANDLE LABEL
20 P0440020 HEX BOLT 5/16-18 X 3/4 71 P0440071 ELECTRICITY LABEL
21 P0440021 OUTLET GASKET 306 X 226MM 72V2 P0440072V2 MACHINE ID LABEL CSA V2.01.12
22 P0440022 OUTLET PORT 73 P0440073 MODEL NO/HP/GRIZZLY LABEL (LARGE)
23 P0440023 HEX BOLT 5/16-18 X 1 74 P0440074 MODEL NO/HP/GRIZZLY LABEL (SMALL)
24 P0440024 FLAT WASHER 5/16 77 P0440077 EXT TOOTH WASHER 3/8
25 P0440025 HEX NUT 5/16-18 78 P0440078 MOTOR MOUNT GASKET
26 P0440026 HOSE CLAMP 7" 79 P0440079 FOAM TAPE 3 X 15 X 600MM
27 P0440027 GRAY FLEX PIPE 7" X 800MM 80 P0440080 CYCLONE VACUUM TUBE
28 P0440028 FILTER L-BRACE (LH) 81 P0440081 FLAT WASHER 5/16
28-1 P0440028-1 BRACE GASKET 155 X 37MM 82 P0440082 HEX BOLT 5/16-18 X 3/4
29 P0440029 FILTER L-BRACE (RH) 83 P0440083 TUBE PLUG 1-1/4"
30 P0440030 HEX BOLT 5/16-18 X 3/4 84 P0440084 FOAM TAPE 3 X 6 X 300MM
31 P0440031 FLAT WASHER 5/16 85 P0440085 VACUUM HOSE 1-1/4" X 98"
32V3 P0440032V3 CANISTER ASSEMBLY (BEIGE) V3.07.12 86 P0440086 COLLECTION DRUM VACUUM TUBE
32V3-1 P0440032V3-1 CANISTER CAGE ASSY (BEIGE) V3.07.12 87 P0440087 FLAT WASHER 5/16
32V2-2 P0440032V2-2 FOAM TAPE 3 X 25 X 1400MM V2.11.09 88 P0440088 HEX BOLT 5/16-18 X 3/4
32V2-3 P0440032V2-3 FOAM TAPE 3 X 35 X 1255MM V2.11.09 89 P0440089 HOSE CLAMP 1-1/4"
32V2-4 P0440032V2-4 CAN FILTER 386MM W/FOAM TAPE V2.11.09 90 P0440090 TUBE PLUG 1-1/4"
32V2-5 P0440032V2-5 BAG CLAMP 445MM V2.11.09 91 P0440091 FOAM TAPE 3 X 6 X 300MM
34V2 P0440034V2 PLASTIC BAG 470 X 600MM V2.11.09 92 P0440092 COLLECTION DRUM VACUUM RING
35 P0440035 FOAM TAPE 3 X 6 X 1600MM 93 P0440093 DRUM COLLECTION BAG 640 X 1000MM
36 P0440036 INTAKE CYLINDER 10" 94 P0440094 JUNCTION BOX
37 P0440037 FLAT WASHER 5/16 95 P0440095 JUNCTION BOX CORD 12G 3C 12"
38 P0440038 HEX BOLT 5/16-18 X 3/4 96 P0440096 GROUNDING WIRE 12G 6" (GREEN)
