Grizzly G0441 User Manual

Model G0440/G0441 (Mfg. Since 03/12)
-49-
G0441 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0441001 MOTOR 3HP 220V 1-PH 43 P0441043 BARREL GASKET 584MM DIA.
1-1 P0441001-1 MOTOR FAN COVER 44V2 P0441044V2 CYCLONE FUNNEL 20" V2.08.10
1-2 P0441001-2 MOTOR FAN 45 P0441045 HEX BOLT 5/16-18 X 1
1-3 P0441001-3 CAPACITOR COVER 46 P0441046 FLAT WASHER 5/16
1-4 P0441001-4 S CAPACITOR 600M 125V 1-3/4 X 3-3/4 47 P0441047 HEX NUT 5/16-18
1-5 P0441001-5 R CAPACITOR 60M 300V 1-5/8 X 3-1/2 48 P0441048 HOSE CLAMP 9"
1-6 P0441001-6 JUNCTION BOX 49 P0441049 CLEAR FLEX PIPE 9" X 340MM
1-7 P0441001-7 BALL BEARING 6205ZZ 50 P0441050 COLLECTION DRUM LID V2.08.06
1-8 P0441001-8 BALL BEARING 6203ZZ 51V3 P0441051V3 DRUM SEAL TYPE-R 2M V3.01.12
1-9 P0441001-9 CONTACT PLATE 52 P0441052 UPPER DRUM 25GAL
1-10 P0441001-10 CENTRIFUGAL SWITCH 3450 53V2A P0441053V2A COLLECTION DRUM ASSY 55GAL V2.11.09
2 P0441002 MOTOR CORD 12G 3C 53V2 P0441053V2 COLLECTION DRUM 35GAL V2.08.10
3V3 P0441003V3 REMOTE MAG SWITCH 220V V3.01.12 54 P0441054 DRUM CLAMP
3V3-1 P0440003V3-1 CONTACTOR NHD C-18D 220V 55 P0441055 HEX BOLT 5/16-18 X 3
3V3-2 P0440003V3-2 OL RELAY NHD NTH-25 21–25A 56 P0441056 HEX NUT 5/16-18
3V3-3 P0440003V3-3 CIRCUIT BOARD 220V W/TRANSFORMER 57 P0441057 DRUM LID LATCH ASSEMBLY
3V3-4 P0440003V3-4 ON/OFF SWITCH 110/220V 58 P0441058 PHLP HD SCR 10-24 X 3/8
4 P0441004 REMOTE CONTROLLER 59 P0441059 HEX NUT 10-24
5 P0441005 HEX BOLT 3/8-16 X 1-1/2 60 P0441060 PHLP HD SCR 10-24 X 3/8
6 P0441006 FLAT WASHER 3/8 61 P0441061 HEX NUT 10-24
7 P0441007 LOCK WASHER 3/8 62 P0441062 CASTER 2"
8 P0441008 HEX NUT 3/8-16 63 P0441063 HEX NUT 3/8-16
9 P0441009 BLOWER COVER 64 P0441064 LOCK WASHER 3/8
10 P0441010 HEX BOLT 3/8-16 X 1-1/2 65 P0441065 FLAT WASHER 3/8
11 P0441011 FLAT WASHER 3/8 66 P0441066 HEX BOLT 5/16-18 X 1
12 P0441012 LOCK WASHER 3/8 67 P0441067 FLAT WASHER 5/16
13 P0441013 HEX NUT 3/8-16 68V2 P0441068V2 SWITCH MOUNTING BRACKET V2.01.12
14A P0441014A IMPELLER 15-1/2" V2.02.06 69 P0441069 HEX NUT 5/16-18
15 P0441015 IMPELLER FENDER WASHER 3/8 70 P0441070 WALL MOUNT BRACKET
16 P0441016 HEX BOLT 3/8-16 X 1 LH 71 P0441071 MOTOR SPEC LABEL
17 P0441017 FOAM TAPE 3 X 6 X 1600MM 72 P0441072 MOTOR WARNING LABEL
18A P0441018A BLOWER HOUSING 15-1/2" IMP V2.02.06 73 P0441073 GLASSES/RESPIRATOR LABEL
19 P0441019 FLAT WASHER 5/16 74 P0441074 READ MANUAL LABEL
20 P0441020 HEX BOLT 5/16-18 X 3/4 75 P0441075 HANDS/INLET LABEL
21 P0441021 OUTLET GASKET 326 X 226MM 76 P0441076 RETURN RED HANDLE LABEL
22 P0441022 OUTLET PORT 77 P0441077 ELECTRICITY LABEL
23 P0441023 HEX BOLT 5/16-18 X 1 78V2 P0441078V2 MACHINE ID LABEL CSA V2.01.12
24 P0441024 FLAT WASHER 5/16 79 P0441079 MODEL NO/HP/GRIZZLY LABEL (LARGE)
25 P0441025 HEX NUT 5/16-18 80 P0441080 MODEL NO/HP/GRIZZLY LABEL (SMALL)
26 P0441026 HOSE CLAMP 8" 83 P0441083 MUFFLER 8"
27A-1 P0441027A-1 GREY FLEX PIPE 8" X 500MM V2.04.08 84 P0441084 EXT TOOTH WASHER 3/8
27A-2 P0441027A-2 GREY FLEX PIPE 8" X 120MM V2.04.08 85 P0441085 FOAM TAPE 3 X 15 X 700MM
28 P0441028 FILTER L-BRACE (RH) 86 P0441086 MOTOR MOUNT GASKET
28-1 P0441028-1 BRACE GASKET 240 X 32MM 94 P0441094 JUNCTION BOX
29 P0441029 FILTER L-BRACE (LH) 95 P0441095 JUNCTION BOX CORD 12G 3C 12"
30 P0441030 HEX BOLT 5/16-18 X 3/4 96 P0441096 GROUNDING WIRE 12G 6" (GREEN)
31 P0441031 FLAT WASHER 5/16 100 P0441100 COLLECTION DRUM EXT KIT
32V3 P0441032V3 CANISTER ASSEMBLY (BEIGE) V3.07.12 101 P0441101 CYCLONE VACUUM TUBE
32V3-1 P0441032V3-1 CANISTER CAGE ASSY (BEIGE) V3.07.12 102 P0441102 FLAT WASHER 5/16
32V2-2 P0441032V2-2 FOAM TAPE 3 X 25 X 1400MM V2.11.09 103 P0441103 HEX BOLT 5/16-18 X 3/4
32V2-3 P0441032V2-3 FOAM TAPE 38 X 35 X 1460MM V2.11.09 104 P0441104 TUBE PLUG 1-1/4"
32V2-4 P0441032V2-4 CANISTER FILTER 486MM V2.11.09 105 P0441105 FOAM TAPE 3 X 6 X 300MM
32V2-5 P0441032V2-5 BAG CLAMP 545MM V2.11.09 106 P0441106 VACUUM HOSE 1-1/4" X 98"
34V2 P0441034V2 PLASTIC BAG 570 X 600MM V2.11.09 107 P0441107 COLLECTION DRUM VACUUM TUBE
35 P0441035 FOAM TAPE 3 X 6 X 1600MM 108 P0441108 FLAT WASHER 5/16
36 P0441036 INTAKE CYCLINDER 10" 109 P0441109 HEX BOLT 5/16-18 X 3/4
37 P0441037 HEX BOLT 5/16-18 X 3/4 110 P0441110 HOSE CLAMP 1-1/4"
38 P0441038 FLAT WASHER 5/16 111 P0441111 TUBE PLUG 1-1/4"
39 P0441039 BARREL GASKET 584MM DIA. 112 P0441112 FOAM TAPE 3 X 6 X 300MM
40 P0441040 INTAKE BARREL 20" 113 P0441113 COLLECTION DRUM VACUUM RING
41 P0441041 HEX BOLT 5/16-18 X 3/4 114 P0441114 DRUM COLLECTION BAG 640 X 1200MM
42 P0441042 FLAT WASHER 5/16
