G0458 18" Open End Belt/Drum Sander

Inventory

After all the parts have been removed from the

box, you should have the following items:

Box 1: (Figures

1 & 2) Qty

A. Drum Sander ..............................................

Figure 1. Box Contents.

Figure 2. Additional box contents.

In the event that any nonproprietary parts are

missing (e.g. a nut or a washer), we would be

glad to replace them, or for the sake of expedi

ency, replacements can be obtained at your local

hardware store.

B. Dust Bag ..................................................... 1

C. Dust Hose Clamp ....................................... 1

D. Dust Port .................................................... 1

E. Stand Legs ................................................. 4

F. Bottom Long Brackets ................................ 2

G. Top Long Brackets ..................................... 2

H. Bottom Short Brackets ............................... 2

I. Top Short Brackets ..................................... 2

J. Hardware and Tools (Not Shown)

— Handwheel ............................................ 1

— Handwheel Handle M10-1.5 ................... 1

— Phillips Head Screw M6-1 x 25 .............. 1

— Flat Washer 5mm .................................. 1

— Hex Bolt M8-1.25 x 20 ........................... 4

— Hex Nut M8-1.25 ................................... 4

— Flat Washer 8mm .................................. 8

— Carriage Bolt M8-1.25 x 15 .................. 16

— Serrated Flange Nut M8-1.25 .............. 16

— Combination Wrench 8/12mm ............... 1

— Hex Wrenches 4, 5, 6mm ................

1 ea
