G0505 12
1
⁄2" Lean & Mean Portable Planer
-25-
1 PSB95M CAP SCREW M5-.8 X 30
2 PLW01M LOCK WASHER 5MM
3 P0505003 CHIP GUARD
4 P0505004 SPONGE PIECE
5 P0505005 UPPER GUARD
6 PSB11M CAP SCREW M8-1.25 X 16
7 PSB01M CAP SCREW M6-1 X 16
8 PLW03M LOCK WASHER 6MM
9 P0505009 HANDLE SET
10 P0505010 HAND KNOB
11 P0505011 HANDLE GUARD
12 P0505012 HANDLE SHAFT
13 PRP07M ROLL PIN 6 X 20
14 P0505014 BUSHING
15 P0505015 ROLLER
16 P0505016 GIB
17 P0505017 CUTTERHEAD
18 PK06M KEY 5 X 5 10
19 P0505019 SPRING
20 P0505020 KNIFE
21 P0505021 GIB LOCK SCREW 1/4"-28
22 P6203 BEARING 6203
23 PR23M INT RETAINING RING 40MM
24 P0505024 CUTTERHEAD PULLEY
25 PN29M HEX NUT M18-2.5
26 P0505026 BELT 135-J6
27 P0505027 UPPER FRAME
REF PART # DESCRIPTION
REF PART # DESCRIPTION
28 PS07M PHLP HD SCR M4-.7 X 8
29 PW05M FLAT WASHER 4MM
30 P0505030 PULLEY GUARD
31 P0505031 CHAIN GUARD
32 PS05M PHLP HD SCR M5-.8 X 8
33 PR21M INT RETAINING RING 35MM
34 P6202 BEARING 6202
35 PSB02M CAP SCREW M6-1 X 20
36 PHTEK7M TAP SCREW M6 X 20
37 P0505037 CHAIN SPROCKET
38 P0505038 CHAIN
39 P0505039 SPACING COLLAR
40 P0505040 RUBBER ROLLER
41 PS09M PHLP HD SCR M5-.8 X 10
42 P0505042 BRACKET PLATE
43 P0505043 ROLLER BRACKET
44 P0505044 BRACKET SPRING
45 PS07M PHLP HD SCR M4-.7 X 8
46 P0505046 INDICATOR
47 P0505047 INDICATION LABEL
48 P0505048 FRAME PIN
49 PLW03M LOCK WASHER 6MM
50 P0505050 GAUGE ROD
51 P0505051 KNIFE SETTING GUIDE
52 PEC10M E-CLIP 9MM
56 P0505056 12 1/2" PLANER LABEL
57 P0505057 MACHINE ID LABEL
58 PLABEL-12 SAFETY GLASSES LABEL
