Model G0529 (Mfd. Since 04/17) -11-
The Model G0529 Oscillating Spindle & 12" Disc
Sander was carefully packed at the factory. If you
discover the machine is damaged after you have
signed for delivery, and the truck and driver are
gone, you will need to file a freight claim with the
carrier. Save the containers and all packing mate-
rials for possible inspection by the carrier or its
agent. Without the packing materials, filing a
freight claim can be difficult. If you need assis-
tance determining whether you need to file a
freight claim, or with the procedure to file one,
please contact our Customer Service.
Box 1 (Figure 3) Qty
A. Sander Unit........................1
B. Left and Right Side Panels............2
C. Front and Pear Panels ...............2
D. Miter Gauge Assembly ...............1
E. Spindle Assemblies
• 2" ..............................1
• 1
1
⁄2" ............................1
•
5
⁄8 " .............................1
•
1
⁄4 " .............................1
F. Table Inserts
• Eliptical Table Insert 2" .............1
• Table Insert 2" ....................1
• Eliptical Table Insert
3
⁄4" .............1
• Table Insert
3
⁄4"....................1
G. Rubber Floor Pads
• Flat Head Screws
5
⁄16"-18 x
3
⁄4"........4
• Washers
5
⁄16"......................4
• Nuts
5
⁄16" ........................4
H. Wrench Hardware Bag
• Open-End Wrench 17mm ...........2
• Open-End Wrench 12mm ...........1
I. Hardware Bag
• Hex Bolts
5
⁄16"-18 x
3
⁄8" ..............8
• Hex Nuts
5
⁄16"-18...................8
• Lock Washers
5
⁄16"................10
• Washers
5
⁄16".....................18
• Hex Bolts
5
⁄16"-18 x
3
⁄4" ..............2
• Hex Wrenches 4, 5, 6mm ........1 Ea.
Figure 3. G0529 inventory.
B
E
C
A
F
D
H
G
I
InventoryUnpacking
SECTION 3: SET UP
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
HEAVY LIFT!
Straining or crushing injury
may occur from improperly
lifting machine or some of
its parts. To reduce this risk,
get help from other people
and use a forklift (or other
lifting equipment) rated for
weight of this machine.
SUFFOCATION HAZARD!
Keep children and pets away
from plastic bags or packing
materials shipped with this
machine. Discard immediately.
