24.
Figure 28.
Figure 28.
25.
Figure 29
Note: During operation, this ring and the
vacuum connection to the cyclone funnel will
prevent the collection bag from collapsing.
Figure 29.
26.
Figure 30
Note: To avoid bag snags, face the screw
heads inside of the drum with the shanks fac-
ing outward.
Figure 30.
27.
Figure 31
Tip: Use an adhesive to keep the seal in
place.
Figure 31.
To Next Page
